GE DS200DCFBG1BNC Industrial grade power module

Specific Parameters

Electrical Parameters
Input Voltage: 38-115V AC (47-63Hz)
Output Voltage: +5V DC, ±15V DC, ±24V DC
Output Current: Maximum 10A (24V DC output)
Voltage Regulation: ±1% (0-100% load change)
Output Ripple: ≤150mVp-p
Communication Interfaces: Ethernet (10/100 Mbps), RS485 (Modbus RTU)
Protection Functions: Overcurrent protection, overvoltage protection, overtemperature protection, short circuit protection
Redundancy Support: N+1 redundant configuration (requires external current sharing resistor)
Environmental Parameters
Operating Temperature: -40°C to +85°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 5% to 95% (non-condensing, stable at 55°C)
EMC Immunity: Compliant with EN 55032 Class B industrial standard
Vibration Resistance: 10-500Hz, 10g acceleration (compliant with IEC 60068-2-6)
Shock Resistance: 30g acceleration, 11ms duration (compliant with IEC 60068-2-27)
Mechanical Parameters
Dimensions: 160mm × 100mm × 30mm
Weight: Approximately 450g
Mounting Method: 3U VME bus slot (with anti-vibration clips)
Protection Class: IP20 (module itself)
Housing Material: Flame-retardant epoxy copper-clad laminate (UL 94 V-0 grade)

Product Performance

DS200DCFBG1BNC adopts a multi-rail power output design, providing +5V, ±15V and ±24V DC power to meet the diverse power supply needs of processors, analog circuits and drive modules in control systems. When load changes suddenly, the output voltage fluctuation can be controlled within ±1%, ensuring stable operation of sensitive equipment.

Built-in voltage and current sensors with intelligent diagnostic circuits, real-time display of working status through onboard LED indicators (green for normal, red for fault). After short circuit or overload faults are eliminated, the module can automatically resume power supply, reducing manual intervention. Channel-level electrical isolation design combined with EMC filtering circuit effectively resists electromagnetic interference in industrial sites and maintains stable output within the wide temperature range of -40°C to +85°C.

Supports VME bus architecture plug-and-play, seamlessly integrable with other modules in the Mark V series. N+1 redundant power supply is achieved through external current sharing resistors when multiple modules are paralleled, with mean time between failures (MTBF) ≥150,000 hours, meeting industrial-grade continuous operation requirements.
