GE DS200ADGIH1AAA Auxiliary interface board

Specific Parameters

Electrical Parameters
Supply Voltage: 24V DC
Current Range: 100A to 400A
Connector Types: 40-pin signal connector 6-pin auxiliary connector
Functional Configuration: 60 configurable jumpers
Alarm Output: Light alarm indication
Interface Standard: Compatible with industrial control bus protocols
Environmental Parameters
Operating Temperature: -20°C to 70°C
Storage Temperature: -40°C to 85°C
Relative Humidity: 5% to 95% (non-condensing)
EMC Immunity: Compliant with EN 61000-6-2 industrial standard
Vibration Resistance: Meeting IEC 60068-2-6 industrial requirements
Mechanical Parameters
Dimensions: 203mm (W) × 152mm (L) (8 inches × 6 inches)
Weight: Approximately 450g
Mounting Method: Screw-fixed installation (adapting to standard control cabinet rails)
Protection Class: IP20 (module itself)
Housing Material: Flame-retardant epoxy copper-clad laminate

Product Performance

DS200ADGIH1AAA adopts high-precision signal isolation circuit to ensure electrical isolation between control signals and feedback signals, with common mode rejection ratio ≥80dB, effectively reducing signal interference in industrial environments. The circuit test point design supports real-time signal monitoring, with fault diagnosis response time ≤50ms, and 直观 indication of abnormal status through light alarm.

Anti-static treatment process meets ANSI/ESD S20.20 standard, reducing the risk of electrostatic damage during operation and maintenance. The module maintains stable signal transmission within the wide temperature range of -20°C to 70°C, with signal delay ≤1ms, ensuring real-time performance of control commands. Mean time between failures (MTBF) ≥100,000 hours, compatible with hardware and software platforms of GE Mark series control systems, supporting seamless integration and configuration.
