GE D20 MIC 10BASE-T Ethernet communication module

GE D20 MIC 10BASE-T Ethernet communication module

SPECIFIC PARAMETERS​

Brand GE​

Product Series D20 Series Industrial Ethernet Communication Module​

Product Type 10BASE-T Industrial-grade Ethernet Communication Module​

Model D20 MIC 10BASE-T​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -20℃ to 60℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In-cabinet Installation)​

Installation Method DIN Rail Installation/Panel Embedded Installation​

Communication Standard IEEE 802.3 10BASE-T​

Data Transmission Rate 10Mbps (Half-duplex/Full-duplex Auto-negotiation)​

Communication Interface 1 Shielded RJ45 Port (With Surge Protection)​

Compatible Protocols TCP/IP UDP ICMP SNMP Modbus TCP​

Network Topology Star/Daisy Chain Topology Support Redundant Network Configuration​

Current Consumption Typical 160mA Maximum 230mA​

Size 105mm×58mm×32mm​

Weight 0.28kg​

Power Consumption Typical 4.8W Maximum 7.5W​

Certification Qualification CE UL CSA IEC 61010-1 IEC 61850-3​

Compatible System GE D20 Series Relay Protection Devices DCS Systems SCADA Systems Industrial Ethernet Devices​

Isolation Feature Electrical Isolation Between Communication Port and Power Supply Isolation Voltage 500VAC​

Diagnostic Function Support Link Status Indication Communication Error Counting Power Supply Fault Detection Network Collision Alarm​

Shielding Level Complies with EN 55032 Class B EMC Standard​

MTBF (Mean Time Between Failures) ≥100,000 Hours​

PRODUCT PERFORMANCE​

Complies with IEEE 802.3 10BASE-T standard, with stable data transmission rate of 10Mbps, ensuring real-time interaction of industrial control commands and monitoring data​

Half-duplex/full-duplex auto-negotiation mode, no manual configuration required to adapt to different network environments, improving on-site deployment efficiency​

RJ45 port integrated with surge protection and shielding design, combined with 500VAC electrical isolation, effectively resisting electromagnetic interference, surge and electrostatic shock in industrial sites​

24VDC wide-range power supply design, withstanding voltage fluctuations and transient sags, ensuring continuous operation of the module in complex power grid environments​

Industrial-grade wide-temperature tolerance capability, can operate stably in the temperature range of -20℃ to 60℃ and non-condensing humidity environment of 5%-95%, adapting to scenarios such as outdoor substations and industrial workshops​

Compatible with mainstream industrial protocols such as TCP/IP and Modbus TCP, enabling seamless communication with SCADA systems, upper computers and distributed intelligent devices, breaking the barrier of system interconnection​

Built-in link status indication and communication error counting functions, fault information is intuitively fed back, facilitating rapid location of network problems and reducing operation and maintenance costs​

Compact size with DIN rail/panel dual installation methods, flexible and convenient installation, saving cabinet space, adapting to different installation scenarios​

Complies with IEC 61850-3 power system communication standard, supports GOOSE message transmission, perfectly adapting to the automation network architecture of smart substations​

Metal ruggedized shell with optimized heat dissipation structure, MTBF of more than 100,000 hours, meeting the 24/7 continuous operation requirements of industrial control networks​

Supports redundant network configuration and daisy chain topology expansion, can flexibly expand the number of network nodes, adapting to the needs of medium and large-scale industrial control networks​
