GE D20 EME 10BASE-T Analog input module

GE D20 EME 10BASE-T Analog input module

SPECIFIC PARAMETERS​

Brand GE​

Product Series D20 Series Industrial Ethernet Communication Module​

Product Type 10BASE-T Industrial Ethernet Communication Module​

Model D20 EME 10BASE-T​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -20℃ to 60℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In-cabinet Installation)​

Installation Method DIN Rail Installation/Panel Installation​

Communication Standard IEEE 802.3 10BASE-T​

Data Transmission Rate 10Mbps (Half-duplex/Full-duplex Selectable)​

Communication Interface 1 RJ45 Port (Shielded)​

Compatible Protocols TCP/IP UDP ICMP SNMP​

Network Topology Star Topology Support Daisy Chain Expansion​

Current Consumption Typical 150mA Maximum 220mA​

Size 110mm×60mm×35mm​

Weight 0.3kg​

Power Consumption Typical 5W Maximum 8W​

Certification Qualification CE UL CSA IEC 61010-1 IEC 61850​

Compatible System GE D20 Series Relay Protection and Control Systems SCADA Systems Industrial Ethernet-compatible Devices​

Isolation Feature Electrical Isolation Between Signal and Power Supply Isolation Voltage 250VAC​

Diagnostic Function Support Link Status Monitoring Communication Abnormality Alarm Power Supply Fault Detection​

Shielding Level Complies with EN 55032 Class A EMC Standard​

PRODUCT PERFORMANCE​

Complies with IEEE 802.3 10BASE-T Ethernet standard, data transmission rate up to 10Mbps, ensuring real-time transmission requirements of industrial control data​

Supports half-duplex/full-duplex mode switching, adapting to different industrial network topology designs and improving network configuration flexibility​

RJ45 shielded interface design, combined with 250VAC electrical isolation between signal and power supply, effectively resisting electromagnetic interference and surge impact in industrial sites​

24VDC wide-range power supply design, resisting power grid fluctuations and voltage sags, ensuring continuous and stable operation of the module in complex industrial environments​

Industrial-grade wide-temperature adaptation capability, can operate reliably in the temperature range of -20℃ to 60℃ and non-condensing humidity environment of 5%-95%​

Compatible with core network protocols such as TCP/IP and UDP, enabling seamless communication with SCADA systems, upper computers and distributed devices to ensure system compatibility​

Supports real-time link status monitoring and communication abnormality alarm, facilitating rapid location of network faults and reducing operation and maintenance costs​

Modular compact design, combined with DIN rail/panel dual installation methods, easy to install and maintain, saving cabinet installation space​

Complies with IEC 61850 power system communication standard, adapting to network interconnection needs of power automation scenarios and ensuring data transmission integrity​

Uses high-quality network chips and ruggedized shells, with long trouble-free operation time, meeting the 24/7 continuous operation requirements of industrial control networks​

Supports daisy chain expansion topology, can flexibly expand the number of network nodes, adapting to medium and large-scale industrial control network architectures​
