GE 745-W3-P5-G5-HI-A-L-R-E-H Advanced Transformer Management Relay, High Performance for Industrial Control Systems

GE 745-W3-P5-G5-HI-A-L-R-E-H Advanced Transformer Management Relay, High Performance for Industrial Control Systems

    Engineered for precision and reliability, the GE 745-W3-P5-G5-HI-A-L-R-E-H is an advanced transformer protection relay designed for critical applications requiring robust monitoring and control.

Operating Environment:Humidity up to 90% non-condensing

Weight:4.8kg

Voltage Relay Input:60 to 120 V

Relay Dimensions:9”H, 7 ⅛”D, 7”W

Overload Withstand:1 second at 80 times rated current, continuous at 3 times rated current

Ground Current Relay Input:5 A

Display Type:40 character LCD

Number of Windings per Phase:Three windings per phase

Control Power Range:90 to 300 VDC; 70 to 265 VAC at 48 to 62 Hz

Analog Input/Output:Available

Loss of Life Options:Included

Restricted Ground Fault:Included

FlexLogic™ Technology:Equation format supporting up to 20 parameters

    The GE 745-W3-P5-G5-HI-A-L-R-E-H is a highly advanced transformer management relay designed to provide unparalleled protection and efficiency for industrial transformers. It is adept at safeguarding transformer systems with its robust design, featuring three windings per phase to optimize current flow and enhance protection against overloads and ground faults.

    This unit operates efficiently within a wide voltage range of 90 to 300 VDC or 70 to 265 VAC, making it suitable for diverse applications across industries. The 5A current rating ensures reliable performance under varying loads.

    The 745-W3-P5-G5-HI-A-L-R-E-H also boasts an enhanced LCD display for easy monitoring and configuration. Its compact dimensions and manageable weight make installation and maintenance straightforward. Moreover, its durable construction withstands harsh environments with a humidity tolerance up to 90% non-condensing, ensuring long-term reliability.

    Designed with adaptability in mind, this relay includes GE Multilin’s FlexLogic™ technology, which allows for the configuration of up to 20 parameters to protect and monitor inputs and outputs effectively. This feature enhances the system’s flexibility and configurability.

    Whether you’re looking to improve the performance of existing transformer systems or integrate new protections into your facility, the GE 745-W3-P5-G5-HI-A-L-R-E-H stands out as a top choice for efficient and reliable transformer management.
