GE 04220FL11232A On site interface and controller module

GE 04220FL11232A On site interface and controller module

Specific Parameters​

Core and Function Parameters​

Product Type Industrial-grade Field Interface and Controller Module​

Manufacturer GE (GE Automation&Controls)​

Model 04220FL11232A​

Series RXI Series​

Core Functions Signal Acquisition and Conversion, Device Connection Management, Complex Motion Control, Data Transmission and Processing, Multi-protocol Communication​

Motion Control Capability Supports up to 64 axes control, realizing online curve calculation, multi-axis interpolation, kinematic conversion​

I/O Channel Configuration 32-channel Analog Input Channels, 16-channel Analog Output Channels, 32-channel Digital Input Channels, 16-channel Digital Output Channels​

Special Function Modules 2-channel High-speed Counters, 1-channel Pulse Generator​

Communication Interfaces RS485 Interface, Ethernet Interface, Two CAN System Bus Interfaces, Two Serial Interfaces​

Supported Protocols Modbus, Ethernet/IP, Profinet, PROFIBUS, Ethernet UDP​

Programming Environment Supports IEC 61131-3 Multi-language Programming, Compatible with PLC Open Function Blocks​

Expansion Capability Supports Multiple I/O Module Expansions, Adapting to Different Industrial Needs​

Configuration Method Network Type, Address and Baud Rate Setting via DIP Switches​

Installation Method Modular Installation, Embeddable in Electronic Drives or Independent Installation​

Certification Standards Certifications Related to Industrial Automation Equipment​

Status Indication Independent Indicators for Power Normal, Operation Status, Communication Status, Fault Alarm​

Electrical and Performance Parameters​

Input Voltage Range 100-240V AC​

Output Voltage 12V DC​

Output Current 3A​

Operating Frequency 50/60Hz​

Control Accuracy 0.5%​

Processor High-performance PowerPC 604e CPU​

Storage Configuration 512MB RAM, 1GB Flash​

Communication Rate Compatible with Corresponding Protocol Standard Rates​

Isolation Level Industrial-grade Electrical Isolation Standard​

Anti-interference Performance Complies with Industrial Electromagnetic Compatibility Standards​

Physical and Environmental Parameters​

Overall Dimensions 120mm×60mm×35mm (Length×Width×Height)​

Weight 200g​

Operating Temperature Range -20°C to 60°C​

Storage Temperature Range -40°C to 85°C​

Relative Humidity 5%-95% (non-condensing, no dew)​

Protection Rating IP65 (per IEC 60529)​

Housing Material High-quality Industrial-grade Material​

Service Life 10,000 Hours​

Vibration Resistance Complies with Industrial Automation Equipment Vibration Standards​

Shock Resistance Complies with Industrial Automation Equipment Shock Standards​

Product Performance​

Rich I/O channel configuration (32-in 32-out digital, 16-in 16-out analog) meets signal processing needs of complex industrial scenarios with strong scalability​

Supports 64-axis complex motion control and high-precision interpolation calculation with 0.5% control accuracy, ensuring precise equipment operation trajectory and stable product quality​

Multi-protocol compatibility + multi-interface design covers mainstream industrial communication protocols, enabling seamless integration into various automation systems with excellent compatibility​

IP65 protection rating + wide operating temperature range resists harsh environments such as dust, humidity, high and low temperatures, with strong adaptability to outdoor and harsh workshop scenarios​

Modular structure supports flexible expansion, DIP switches for quick network parameter configuration, easy installation and commissioning with high operation and maintenance efficiency​

High-performance processor + large-capacity storage quickly processes complex control algorithms and massive data, with fast response and smooth operation​

High-quality materials and strict processes ensure 10,000-hour long service life, low failure rate and strong long-term operation reliability​

Supports IEC 61131-3 multi-language programming, adapting to different engineers’ operating habits with high development and deployment flexibility​
