FOXBORO FBM240 P0917GZ Digital I/O module

FOXBORO FBM240 P0917GZ Digital I/O module

Specific Parameters

Brand Foxboro (American Brand, a Subsidiary of Emerson)

Product Series I/A Series DCS Card, Compact200 Series

Product Type Industrial-Grade Digital I/O Module (DCS Card)

Model FBM240 P0917GZ

Number of Input Channels 8 Digital Input Channels

Number of Output Channels 8 Digital Output Channels

Input Type Discrete Input (Reading Voltage Through Relay Contacts)

Output Type Discrete Relay Output

Output Switching Capacity 10A @ 80-120VAC; 5A @ 80-125VDC; 5A @ 15-30VDC

Channel Isolation 15-60VDC @ 2A, Fused Output

Memory 16MB SDRAM, 32MB Flash

Supply Voltage 24VDC (Typical Value)

Maximum Power Consumption Maximum 8.5W for Non-Fault-Tolerant Modules

Operating Temperature Range -40℃ to +60℃

Storage Temperature Range -40℃ to +85℃

Network Transmission Rate Supports Redundant 10Mbps or 100Mbps Ethernet

Configuration Mode Supports Single or Redundant Module Configuration

Firmware Requirement Firmware Version 1.40N or Later Required for Fail-Safe Configuration

Connection Method On-Site I/O Connected to Common Terminal Assembly (TAs), Supporting Local/Remote Wiring

Isolation Function Equipped with Channel Isolation and System Isolation Functions to Resist External Interference

Certification Standards CE Certification

Product Performance

Equipped with 8 digital input channels and 8 digital output channels, it realizes high-density I/O integration, which can meet the signal collection and control needs of a large number of I/O points in complex industrial control systems and improve system integration efficiency.

Supports redundant configuration, can be used as a single or redundant module, provides redundancy protection at the FBM level, and each module independently maintains the specified output value and reads the observed value, greatly improving system reliability and fault tolerance.

It has complete fault detection function, which can read input voltage through relay contacts. When the contact state is inconsistent with the corresponding output channel state, it automatically sets the channel BAD, facilitating timely detection and handling of abnormalities.

Built-in channel isolation and system isolation functions, which can effectively resist electromagnetic interference in industrial sites, avoid signal distortion and module damage, and ensure the stability and accuracy of I/O signal collection and transmission.

Adopting a compact modular design, combined with Terminal Assembly (TAs), it supports local or remote on-site wiring, is easy to install, saves the installation space of the control cabinet, and adapts to various industrial on-site layouts.

Equipped with 16MB SDRAM and 32MB Flash memory, supports redundant 10/100Mbps Ethernet transmission, has fast data processing speed, can quickly respond to changes in on-site signals, and meets the real-time control needs of industrial processes.

Supports fail-safe configuration (requires corresponding firmware version) and has fail-safe rollback function, ensuring the safe operation of the system in abnormal situations and avoiding production accidents.

Adopting 24VDC stable power supply, the maximum power consumption of non-fault-tolerant modules is only 8.5W. The low-power design combined with the wide temperature operation capacity of -40℃ to +60℃ enables long-term stable operation in high temperature and harsh electromagnetic environments.

Fully compatible with FOXBORO I/A Series DCS system and Compact200 Series I/O subsystem, it can be seamlessly integrated into the existing system without additional modification, with strong compatibility.
