EMERSON OVATION 5X00121G01 Input feature module

EMERSON OVATION 5X00121G01 Input feature module

Specific Parameters

Brand Emerson (American Brand), Ovation Series Under Its Umbrella

Product Series Ovation DCS System RTD Input Module Series

Product Type 8-Channel RTD Input Personality Module (PMOD)

Model 5X00121G01

Number of Channels 8 Independent RTD Input Channels

Supported RTD Types Pt100, Pt1000, Cu100 and Other RTDs

Input Temperature Range -200℃ to +850℃

Measurement Accuracy ±0.01%FS

Resolution 12 Bits

Sampling Rate 16.67 Samples/Second Normally at 50Hz Mode, 3 Samples/Second at 3-Wire Mode; 20 Samples/Second Normally at 60Hz Mode, 2 Samples/Second at 3-Wire Mode

Calibration Mode On-Demand Self-Calibration, Sampling Rate Drops to 1 Sample/Second During Calibration Period

Matching Module Only Compatible with 5X00119G01 Electronic Module (RTD EMOD)

Supply Voltage 24VDC

Maximum Channel Current 50mA per Channel

Power Consumption Less Than 5W

Communication Protocol Modbus RTU

Operating Temperature Range -40℃ to +85℃

Storage Temperature Range -40℃ to +85℃

Relative Humidity ＜95%RH, No Condensation

Protection Level IP65

Shell Material Aluminum Alloy

Physical Dimensions 125mm×105mm×35mm (Width×Height×Depth)

Physical Weight Approximately 0.32kg

Mounting Method Wall-Mounted Installation, Supports Hot Swapping

Application Restriction Not Applicable to CE Certified Systems

Product Performance

Adopting an 8-channel independent RTD input design, it supports various RTD types such as Pt100, Pt1000, and Cu100, and can collect 8 channels of on-site industrial temperature signals at the same time, meeting the needs of multi-point temperature monitoring and improving system integration efficiency.

The measurement accuracy reaches ±0.01%FS with a resolution of 12 bits, which can accurately capture subtle changes in temperature during industrial processes, provide reliable data basis for temperature control and fault diagnosis, and ensure the accuracy of monitoring results.

It has a self-calibration function, which can complete calibration operations on demand. The sampling rate automatically drops to 1 sample/second during the calibration period, without manual intervention, reducing operation and maintenance costs and ensuring long-term measurement accuracy.

Supports hot swapping function, which can complete module installation, replacement and maintenance without shutting down the entire DCS system, greatly shortening system downtime and improving operation and maintenance efficiency and system continuity.

Adopting an aluminum alloy shell design, it has excellent anti-electromagnetic interference ability, which can effectively resist interference from complex electromagnetic environments in industrial sites, avoid signal distortion, and ensure the stability of data transmission.

It is only used with the 5X00119G01 electronic module, fully compatible with all series of Ovation DCS control systems, and can be seamlessly integrated without additional modification, with extremely strong compatibility.

With a protection level of IP65, it has excellent dustproof and waterproof performance, combined with a wide temperature operation capacity of -40℃ to +85℃, it can operate stably for a long time in harsh industrial environments such as high temperature, low temperature and high dust.

Adopting 24VDC stable power supply, the maximum channel current is 50mA, and the power consumption is less than 5W. The low-power design can reduce the overall energy consumption of the system and ensure the long-term stable operation of the module.

Supports Modbus RTU communication protocol, which can quickly realize data interaction with the Ovation DCS controller, with low data transmission delay, meeting the needs of real-time temperature monitoring in industrial processes.
