EMERSON FX-4120 960121-01 Communication servo drive module
Specific parameters
Power parameters: Input voltage is 240V AC, frequency is 60Hz, 3-phase power supply; The auxiliary logic power supply is 96-264V AC 1 Ø, used for 1-1000 lb inches; The bridge power supply is 96-264V AC 1 Ø or 3 Ø, suitable for different torque ranges.
Torque parameters: When used in combination with DX series (0-120 pound inches) and BL series (120-1000 pound inches) rotary transformer feedback servo motors, continuous torque of 0-1000 pound inches can be obtained.
I/O parameters: The basic FX-4120 driver comes standard with 8 input lines and 4 output lines (10 to 30VDC), which can be input or output. Additional I/O can be added by installing application modules, including 8 inputs and 4 outputs.
Communication parameters: Equipped with RS-232 communication interface, with a baud rate of up to 19.2Kbaud, it can connect up to 31 FX drives in a daisy chain manner on a single communication link.
Product Performance
High control accuracy: With a fully digital design, it can achieve high-precision position, speed, and torque control, meeting various precision motion control requirements.
Easy programming: Users can easily program using EMERSON Motion Control’s PCXWin or PCX for DOS fill in the blank software, making it convenient for parameter settings and function configurations.
Diverse operating modes: It has multiple operating modes such as overall locator, simulated speed, simulated torque, pulse follower, etc., which can be flexibly selected according to different application scenarios.
Complete diagnostic function: equipped with LED display screen, it can display the operation and diagnostic status in real time, making it convenient for users to quickly understand the operation status of the equipment, discover and solve problems in a timely manner.
Strong scalability: Application modules can be installed on basic drives, adding additional I/O, memory, and various special application functions to meet application requirements of different levels of complexity.
