EATON CS-TX3-3 81X2.54-64TW Spring terminal block

EATON CS-TX3-3 81X2.54-64TW Spring terminal block

Specific Parameters

• Electrical Parameters
  Rated Voltage: 600V AC/DC
  Rated Current: 16A/terminal (at 25°C)
  Contact Resistance: ≤5mΩ (initial value)
  Insulation Resistance: ≥1000MΩ (tested at 500V DC)
  Withstand Voltage: 2500Vrms (for 1 minute, between terminals/terminal and ground)
• Mechanical Parameters
  Terminal Pitch: 2.54mm
  Number of Terminals: 81 channels (3 rows×27 channels)
  Connection Method: Spring pressure connection (tool-free)
  Wire Range: 0.14-2.5mm² (AWG 26-14)
  插拔次数: ≥50 times (terminal cover operation)
• Environmental Parameters
  Operating Temperature Range: -40°C to +85°C
  Storage Temperature Range: -50°C to +100°C
  Relative Humidity: 5% to 95% (non-condensing)
  Protection Class: IP20 (module body)
  Vibration Resistance: Complies with IEC 60068-2-6 standard (10-500Hz, 15g)
• Physical Parameters
  Mounting Method: 35mm DIN rail mounting (compatible with TS35/7.5 and TS35/15)
  Dimensions (L×W×H): 210mm×30mm×50mm
  Weight: Approximately 0.45kg
  Material: Flame-retardant PA66 housing (UL94 V-0), terminal material: tinned copper alloy

Product Performance

• High-Density Signal Distribution: The 2.54mm pitch design integrates 81 terminals, saving 40% of control cabinet space, suitable for automation equipment requiring a large number of signal accesses (such as CNC machine tools, process control systems).
• Tool-Free Quick Wiring: Spring pressure connection technology supports one-handed wire insertion, improving wiring efficiency by 70%, and has an anti-loosening self-locking function to ensure connection stability in vibrating environments.
• High-Reliability Contact: Gold-plated contacts (thickness ≥3μm) and anti-oxidation coating resist industrial environmental corrosion, with contact resistance increase ≤10% after salt spray test (5% NaCl solution, 96 hours).
• Wide Temperature Stability: In the full temperature range of -40°C to +85°C, terminal resistance drift ≤3%, adapting to severe cold regions and high-temperature industrial scenarios.
• Intelligent Diagnosis Function: Optional LED status indicator module for real-time monitoring of each terminal’s on/off status, with fault location accuracy reaching single-channel level.
