CCC MCP-1004 Signal conversion module

Supply Voltage: 10-30V DC (5V DC customization supported)

Rated Power Consumption: Current consumption ＜110mA at 24V DC, ＜190mA at 12V DC

CPU Frequency: 1GHz (Extreme Engineering architecture)

Communication Protocols: Supports Modbus-RTU, Profibus-DP

Data Interfaces: RS485 (half-duplex), Ethernet (10/100Mbps)

Output Mode: Parallel output (supports Gray code, binary coding)

Single-turn Resolution: 1/4096

Repeat Positioning Accuracy: ＜2Bit

Isolation Voltage: 2.5kVrms (between input and output channels, duration 1 minute)

Operating Temperature Range: -40℃ to +85℃ (no condensation)

Storage Temperature Range: -40℃ to +90℃

Relative Humidity: 5% to 95% RH (no condensation at 40℃)

Vibration Resistance: Complies with IEC 60068-2-6 standard (10Hz-2000Hz, 10g acceleration, 30 minutes per axis)

EMC Immunity: Complies with EN 61000-6-2 standard (ESD ±15kV air discharge, ±8kV contact discharge)

Protection Class: IP65 (dustproof and waterproof, suitable for outdoor and humid industrial environments)

Mounting Method: 35mm standard DIN rail mounting/panel screw fixing

Overall Dimensions (L×W×H): 120mm×80mm×30mm (excluding terminals)

Net Weight: 200g (including housing and internal components)

Housing Material: Flame-retardant ABS plastic (UL94 V-0 grade, anti-corrosion treatment)

Wiring Method: Spring crimp terminals (suitable for conductor cross-sectional area 0.5-2.5mm²)

Status Indication: LED indicators (1 for power, 1 for operation, 1 for communication, 1 for fault, single-color display)

High Computing Power Processing: 1GHz frequency CPU supports multi-task parallel computing, with single control instruction execution delay ≤1ms. It can run 3 channels of compressor closed-loop control algorithms simultaneously, meeting the multi-parameter collaborative regulation needs of large-scale compressor units.
Wide Voltage Adaptability: 10-30V DC power supply range is compatible with different specifications of power supplies in industrial sites. It maintains stable output signals within the voltage fluctuation range of ±10% without additional voltage stabilization modules.
Precise Positioning Control: 1/4096 single-turn resolution and ＜2Bit repeat positioning accuracy ensure precise control of executive mechanisms such as compressor valve opening and motor speed, with errors controlled within the industrial allowable range.
Strong Environmental Tolerance: -40℃ to +85℃ operating temperature range and IP65 protection class allow continuous operation in harsh environments such as oilfield wellheads and chemical workshops, with Mean Time Between Failures (MTBF) ≥100,000 hours.
Flexible System Integration: Compatible with mainstream industrial bus protocols and DCS systems, supporting cascade expansion of 64 modules. A single network can manage 128 compressor devices, adapting to large-scale industrial control scenarios.
