B&R 3DM4766 Analog Mixed Module

B&R 3DM4766 Analog Mixed Module

    The B&R 3DM4766 Analog Hybrid Module is designed for industrial control systems, offering a versatile solution for integrating analog signals with digital control logic. This module supports multiple input and output configurations, making it ideal for applications requiring high precision and reliability.

Manufacturer:B&R

Model:3DM4766

Channels:32

Voltage Range:±10V

Current Range:±20mA

Sampling Rate:Up to 100kHz

Resolution:16-bit

Interface:PROFINET, PROFIBUS

Power Supply:24V DC

Operating Temperature:-40°C to 85°C

Storage Temperature:-55°C to 105°C

Protection Rating:IP20

Certifications:CE, UL, RoHS

    The B&R 3DM476.6 Mixed Signal Module is designed to provide robust performance in industrial environments. With 32 channels capable of handling both analog and digital signals, this module ensures seamless integration into any control system. Its compact design and reliable power supply make it an ideal choice for a wide range of industrial applications. The module supports 16 channels of 12-bit analog input, allowing for precise measurement and control. It also features 16 channels of 24V DC digital inputs, providing additional flexibility in signal handling. Operating within a temperature range of -25°C to +70°C, the 3DM476.6 can withstand harsh environmental conditions. Its dimensions are 120mm x 90mm x 60mm, making it easy to install in tight spaces. Weighing approximately 0.5kg, it’s lightweight yet durable. This module is perfect for manufacturers looking to enhance their control systems with high precision and reliability.
