Bently Nevada 3500/65 145988-02 Digital Input/Output Module Kit

Specific Parameters

3500/65 Digital I/O Module
Electrical Parameters
Supply Voltage: 5V DC ±5% (provided by 3500 system frame)
Input Channels: 8 digital inputs, compatible with dry contact/active signal
Output Channels: 4 digital outputs, relay contact output
Input Signals:
Dry Contact: Minimum 0.5mA (24V DC excitation)
Active Signal: 24V DC (high level 18-30V, low level 0-5V)
Output Load:
Rated Voltage: 250V AC/30V DC
Rated Current: 5A (resistive load), 1A (inductive load)
Response Time: Input ≤1ms, Output ≤5ms
Isolation Level:
Between Channels: 2.5kV AC (1 minute)
Between I/O and System: 5kV AC (1 minute)
Protection Functions: Input overvoltage protection (≤35V DC), output short-circuit protection, reverse polarity protection
Power Consumption: ≤9W under normal operation
Environmental Parameters
Operating Temperature: 0°C to 65°C
Storage Temperature: -40°C to 85°C
Relative Humidity: 5% to 95% (non-condensing, no dew formation)
EMC Immunity: Compliant with EN 61326-1 (industrial grade), IEC 61000-4-2/4/6
Vibration Resistance: 10-500Hz, 2g acceleration (compliant with IEC 60068-2-6)
145988-02 Dedicated Terminal Board
Electrical Parameters: Supports 8-input & 4-output signal transfer, 2.5kV AC isolation between channels
Mechanical Parameters: Dimensions 120mm×85mm×25mm, weight approximately 150g
Terminal Configuration: 24-position spring-loaded crimp terminals (compatible with 14-22 AWG wires)
Mounting Adaptation: Side-mounted on 3500 system frame, with signal identification and ground terminals
Overall Mechanical Parameters
Module Dimensions: 40mm (W) × 160mm (H) × 220mm (D)
Module Weight: Approximately 550g
Mounting Method: 3500 system frame standard slot mounting
Protection Class: IP20 (module itself)
Housing Material: Flame-retardant aluminum alloy (UL 94 V-0 grade)

Product Performance

The kit adopts independent channel isolation design, 8 inputs support mixed access of dry contact and active signals, and signal types can be configured via software without hardware jumpers, adapting to diverse on-site equipment. 4 relay outputs adopt forced-guided contact structure, ensuring no misoperation when single contact fails, meeting SIL 2 safety level requirements.

Integrated with programmable logic control function, it supports basic logic such as AND/OR/NOT and complex instructions such as delay and edge detection, with logic operation cycle ≤1ms, enabling rapid interlock response of fault signals. Data interaction delay with 3500 system monitoring module is ≤3ms, supporting input signal debounce setting (1ms-10s adjustable) to effectively filter on-site interference signals.

Built-in comprehensive self-diagnosis functions, it can real-time monitor input open circuit, output short circuit, relay sticking and module power abnormalities, with diagnostic coverage ≥99%, and fault status fed back through dual channels of LED indicators and system bus. Wide temperature adaptability and high isolation level design ensure stable operation in industrial strong electromagnetic environments, with overall mean time between failures (MTBF) ≥300,000 hours.
