Bently Nevada 3500/42M 140482-01 140734-02 Rotating Machinery Vibration and Position Monitoring Kit

Specific Parameters

3500/42M Monitoring Module
- Electrical Parameters
  - Supply Voltage: 5V DC ±5% (provided by 3500 frame)
  - Input Channels: 4 independent differential inputs
  - Signal Types:
    - Vibration: Acceleration (0-50g), Velocity (0-500mm/s), Displacement (0-2000μm)
    - Position: Shaft displacement (-500μm to +500μm), Differential expansion (0-50mm)
  - Measurement Accuracy: ±0.1% full scale
  - Resolution: 24-bit A/D conversion
  - Sampling Rate: 1024 points/sec/channel
  - Output Signals: 4×4-20mA analog outputs, 2×Form-C relay outputs (250V AC/30V DC, 5A)
  - Communication Interface: 3500 system backplane bus (100Mbps)
  - Protection Functions: Overvoltage protection (≤30V DC), short circuit protection, channel isolation protection
  - Power Consumption: ≤8W
- Environmental Parameters
  - Operating Temperature: 0°C to 65°C
  - Storage Temperature: -40°C to 85°C
  - Relative Humidity: 5% to 95% (non-condensing, no dew formation)
  - EMC Immunity: Compliant with EN 61326-1 (industrial grade)
  - Vibration Resistance: 10-500Hz, 2g acceleration (compliant with IEC 60068-2-6)
140482-01 Terminal Board
- Electrical Parameters: 2.5kV AC (1 minute) isolation between channels, supporting differential signal access
- Mechanical Parameters: Dimensions 100mm×80mm×20mm, weight approximately 100g, 3500 frame compatible mounting
- Terminal Type: Spring-loaded crimp terminals (compatible with 16-22 AWG wires)
140734-02 Connection Cable
- Electrical Parameters: Shielded twisted pair, impedance 100Ω±10%, transmission distance ≤10m
- Mechanical Parameters: Outer diameter 6mm, weight approximately 0.1kg/m, oil-resistant PVC sheath
Overall Mechanical Parameters
- Module Dimensions: 40mm (W) × 160mm (H) × 220mm (D)
- Module Weight: Approximately 500g
- Mounting Method: 3500 system standard frame slot mounting
- Protection Class: IP20 (module itself)
- Housing Material: Flame-retardant aluminum alloy (UL 94 V-0 grade)

Product Performance

The kit adopts 24-bit high-precision A/D conversion chip and anti-aliasing filter circuit, with vibration signal measurement error ≤0.1% and shaft displacement measurement resolution up to 0.1μm, ensuring accurate equipment condition data acquisition. 4-channel independent signal conditioning design supports synchronous sampling with sampling rate 1024 points/sec/channel, which can capture high-frequency vibration impact signals.

Integrated with real-time fault diagnosis function, it supports peak/peak-to-peak monitoring, spectrum analysis (0-10kHz) and trend tracking, with fault response time ≤10ms, triggering equipment interlock protection via relay output. Data transmission delay with 3500 system controller is ≤5ms, supporting online configuration parameters (alarm value, range) and firmware upgrade without shutdown for maintenance.

Wide temperature design combined with shielded cable provides common mode rejection ratio ≥100dB, effectively resisting electromagnetic interference in industrial sites. The overall mean time between failures (MTBF) ≥300,000 hours, complying with API 670 rotating machinery monitoring standard and SIL 2 safety level requirements.
