Bently Nevada 330876-03-50-00-00 Special connection cable assembly for mechanical eddy current sensor

Specific Parameters

Electrical Parameters
Cable Type: Two-core shielded cable with independent signal core and common ground core
Signal Transmission: Supports eddy current probe gap voltage (-2V to -18V DC) and vibration signal transmission
Impedance Characteristics: Conductor DC resistance ≤5Ω/100m, insulation resistance ≥100MΩ (500V DC)
Capacitance Parameters: Capacitance between conductors ≤100pF/m, capacitance between conductor and shield ≤200pF/m
Shielding Performance: Tinned copper braided shield, coverage ≥90%
Operating Voltage: Maximum 30V DC (powered by proximitor)
Frequency Response: 0-10kHz (no signal transmission attenuation)
Environmental Parameters
Operating Temperature: -55°C to 125°C (fixed installation), -40°C to 85°C (mobile installation)
Storage Temperature: -65°C to 150°C
Relative Humidity: 0% to 100% (full temperature range, including condensation)
EMC Immunity: Compliant with EN 50155 (rail transit grade), IEC 61000-4-6
Vibration Resistance: 10-2000Hz, 10g acceleration (compliant with IEC 60068-2-6)
Protection Class: IP67 (connector part), cable body oil-resistant and chemical-resistant
Mechanical Parameters
Cable Dimensions: Outer diameter 6.5mm, conductor cross-sectional area 0.22mm²
Cable Length: 5 meters (the “50” in the model corresponds to 5m, other lengths customizable)
Connector Type: One end is 10-32 UNF threaded straight connector, compatible with 3300 XL probes; the other end is BNC straight connector, compatible with 3300 XL proximitors
Weight: Approximately 0.15kg/m
Bending Radius: Static ≥25mm, dynamic ≥50mm
Sheath Material: Flame-retardant polyether polyurethane (PUR), UL 94 V-0 grade

Product Performance

The cable assembly adopts a two-core independent shielding structure combined with a braided shield with over 90% coverage, providing common mode rejection ratio ≥120dB, which can effectively resist high-frequency electromagnetic interference generated by equipment such as frequency converters and motors in industrial sites, ensuring vibration signal transmission error ≤0.1%. The 0-10kHz wide frequency response characteristic can completely retain high-frequency vibration impact signals (up to 10kHz) collected by eddy current probes, adapting to the early fault diagnosis needs of rotating machinery.

The -55°C to 125°C wide operating temperature range, combined with oil-resistant PUR sheath, enables long-term stable operation in harsh environments such as petrochemical and metallurgy, with cable service life ≥10 years. The IP67 waterproof connector adopts a threaded locking design, with plug-in life ≥500 times, and signal attenuation at the connection ≤0.05dB, ensuring long-term connection reliability.

Fully compatible with 3300 XL series probes and proximitors, signal transmission delay ≤1μs, which can be directly integrated into Bently Nevada 3500 monitoring system without additional adaptation components, with mean time between failures (MTBF) ≥500,000 hours.
