Autoliv Sim.Mod. B0760 627913600B Analog signal processing module

Autoliv Sim.Mod. B0760 627913600B Analog signal processing module

Specific Parameters​

Electrical Parameters​

Supply Voltage 9V DC-16V DC, compatible with automotive battery power supply system​

Quiescent Current ≤40mA, Operating Current ≤180mA​

Analog Signal Input 12 differential channels, input range ±10V​

Signal Conditioning Accuracy ±0.1% full scale, support signal amplification 1-1000 times adjustable​

ADC Resolution 16 bits, conversion rate 100kHz​

Digital Signal Output 8 TTL level outputs, compatible with CAN 2.0B protocol​

Output Current Maximum 1A per channel, support short-circuit protection​

Isolation Level 2500V AC between input and output, complying with ISO 10605 standard​

Response Time ≤3ms, realizing real-time signal processing and transmission​

Mechanical and Environmental Parameters​

Overall Dimensions 68mm×48mm×21mm, compact structure​

Weight 145g, lightweight design suitable for vehicle installation space​

Mounting Method Bolt fixing, compatible with installation at rear of instrument panel and chassis bracket​

Protection Rating IP6K9K, with waterproof, dustproof and high-temperature flushing resistance​

Operating Temperature -40℃ to 85℃, covering full vehicle operating environment​

Storage Temperature -55℃ to 125℃, meeting extreme storage and transportation requirements​

Vibration Level Complies with ISO 16750-3 standard, withstanding 10Hz-2000Hz vibration (acceleration 20g)​

EMC Compliance Complies with ISO 11452-4 standard, radiated emission ≤30dBμV/m​

Product Performance​

High signal processing accuracy, ±0.1% full-scale conditioning accuracy ensures sensor data accuracy​

Extremely fast response speed, ≤3ms delay ensures rapid triggering of safety systems in collisions​

Strong operational stability, selection of automotive-grade components, Mean Time Between Failures (MTBF) ≥120000 hours​

Excellent anti-interference capability, complying with automotive EMC standards, no signal distortion or disorder​

Wide adaptation range, compatible with safety architectures of multi-brand passenger cars, commercial vehicles and new energy vehicles​

Reliable protection performance, IP6K9K rating resists high-pressure water flushing and dust erosion​

Comprehensive testing functions, supporting signal simulation of collision scenarios to assist safety system development and verification​

Reasonable power consumption control, low quiescent current design reduces vehicle standby energy consumption​
