Autoliv 627844200C Special control module for automotive safety system

Autoliv 627844200C Special control module for automotive safety system

Specific Parameters​

Electrical Parameters​

Supply Voltage 9V DC-16V DC, compatible with automotive battery power supply system​

Operating Current Static ≤50mA, operating state ≤300mA​

Signal Input Type 4 channels of analog input, 8 channels of digital input​

Signal Output Type 6 channels of transistor output, 2 channels of relay output​

Output Current Transistor output maximum 2A per channel, relay output maximum 5A per channel​

Isolation Level 2500V AC isolation between input and output, complying with ISO 10605 standard​

Response Time ≤10ms, realizing real-time signal processing​

Communication Protocol Supports CAN 2.0B, communication rate up to 1Mbps​

Mechanical and Environmental Parameters​

Overall Dimensions 65mm×45mm×20mm, compact design​

Weight 1.2kg, lightweight structure suitable for vehicle installation​

Mounting Method Bolt fixing, compatible with installation at vehicle chassis or rear of instrument panel​

Protection Rating IP6K9K, with waterproof and dustproof capabilities​

Operating Temperature -40℃ to 85℃, meeting full vehicle operating conditions​

Storage Temperature -55℃ to 125℃, adapting to extreme storage environments​

Vibration Level Complies with ISO 16750-3 standard, withstanding 10Hz-2000Hz vibration​

Shock Level 100g peak acceleration, duration 11ms​

Product Performance​

Fast signal processing, ≤10ms response time ensuring immediate execution of braking or safety commands​

Strong environmental adaptability, wide temperature and vibration range adapting to various climates and road conditions​

High operational reliability, automotive-grade components and isolation design, MTBF ≥100000 hours​

Excellent anti-interference capability, complying with ISO 11452 EMC standard, no signal disorder​

Comprehensive diagnostic function, real-time monitoring of circuit status, triggering alarm signals when faulty​

Strong compatibility, adapting to braking and safety system architectures of multi-brand vehicles​

Excellent protection performance, IP6K9K rating resisting high-pressure water and high-temperature flushing during car washing​

Outstanding power consumption control, low quiescent current reducing vehicle standby energy consumption​
