ASSEMBLY #0100-71267 controller module

ASSEMBLY #0100-71267 controller module

Specific Parameters​

Electrical Parameters​

Operating Voltage 24V DC, compatible with industrial standard DC power supply systems​

Rated Current 5A, single-channel output current ≤1A (total 5 independent electrical circuits)​

Insulation Resistance ≥100MΩ (tested at 500V DC), ensuring electrical safety​

Withstand Voltage 1500V AC, no breakdown or flashover for 1 minute​

Signal Transmission Rate Up to 1Mbps, supporting digital signal and analog signal (0-10V/4-20mA) transmission​

Interface Type Standard 5-channel terminal interfaces (M3 screw fastening), 2-channel RJ45 communication interfaces​

Protection Rating IP65 for electrical parts, with dustproof and low-pressure water spray proof capabilities​

Compatible Signals Supports NPN/PNP sensor signals, incremental encoder A/B phase signals​

Mechanical Parameters​

Overall Dimensions 200mm×150mm×80mm (L×W×H), adapting to standard equipment installation space​

Weight 1.8kg, using high-strength materials to balance light weight and stability​

Material Main body: 6061 aluminum alloy (anodized surface), connectors: 304 stainless steel​

Mounting Method Supports 4 M5 threaded hole fixing (hole spacing 180mm×130mm), compatible with rail-type auxiliary mounting​

Mechanical Strength Static load capacity ≥50kg (vertical direction), impact resistance ≥100N (instantaneous)​

Adaptable Interfaces Compatible with DIN 41612 standard connectors, supporting quick plug-in​

Operating Temperature Range -30℃ to 80℃, no mechanical performance attenuation over the entire temperature range​

Environmental Parameters​

Operating Temperature -30℃ to 80℃, no performance derating over the entire temperature range​

Storage Temperature -40℃ to 90℃, meeting extreme storage and transportation requirements​

Relative Humidity 5% to 95% (non-condensing), adapting to high-humidity industrial scenarios​

Vibration Resistance Complies with IEC 60068-2-6 standard, 3g acceleration in 10Hz-500Hz frequency range (duration 2 hours)​

Shock Resistance Complies with IEC 60068-2-27 standard, 20g acceleration (duration 11ms, 5 times each in X/Y/Z directions)​

Corrosion Resistance 48-hour salt spray test (GB/T 10125 standard), no obvious rust​

Product Performance​

High integration, integrating 5 independent electrical circuits and communication interfaces, reducing equipment wiring complexity​

Strong electrical safety, high insulation resistance and withstand voltage characteristics, avoiding equipment damage caused by electrical faults​

Good mechanical stability, high-strength material and reasonable structural design, withstanding vibration and impact during equipment operation​

Reliable signal transmission, anti-interference circuit design, analog signal transmission error ≤0.5%, no digital signal packet loss​

Wide installation adaptability, standardized mounting holes and interfaces, compatible with various industrial equipment structures​

Strong environmental tolerance, -30℃ to 80℃ wide temperature operation + IP65 protection, adapting to harsh industrial working conditions​

High maintenance convenience, modular structure supporting single component replacement without overall disassembly​

Excellent compatibility, adapting to sensors and actuators of different brands, reducing equipment selection restrictions​
