Analog Devices LT8620MPMSE – High-Efficiency Power Management Module

Analog Devices LT8620MPMSE – High-Efficiency Power Management Module

    The ADI LT8620MPMSE is a high-efficiency, multi-output power management solution designed for industrial automation systems. It offers precise voltage regulation and low ripple noise performance, making it ideal for demanding applications requiring reliable power delivery.

Manufacturer:Analog Devices

Model:LT8620

Submodel:MPMSE

Module Category:Power Management

Input Voltage Range:4.5V to 36V

Output Voltage Range:0.6V to 18V

Output Current:Up to 2A

Efficiency:Up to 96%

Switching Frequency:Up to 2MHz

Operating Temperature Range:-40°C to +125°C

Package Type:MSOP-10

Certifications:RoHS Compliant, CE Approved

    The LT8620MPMSE from Analog Devices is an ideal choice for space-constrained designs requiring high-performance power conversion. This module features a monolithic architecture that integrates all necessary components including power switches, inductor, and control circuits in a single package. The device operates at a high switching frequency of up to 3MHz, enabling the use of small external components and reducing the overall solution size. With its high efficiency up to 96%, it is perfect for battery-operated devices or systems where thermal dissipation is a concern. The LT8620MPMSE includes internal compensation, simplifying design and reducing external component count. Its robust design allows it to operate over a wide temperature range (-40°C to +125°C), making it suitable for harsh environments. The module’s small form factor (8-Lead 3mm x 3mm QFN package) and easy-to-use interface make it an excellent choice for modern power supply applications.
