ALSTOM V0701596-001102 High frequency power controller module

ALSTOM V0701596-001102 High frequency power controller module

SPECIFIC PARAMETERS​

Brand ALSTOM​

Product Series Industrial High-frequency Power Supply Controller Module Series​

Product Type Special Controller Module for Electrostatic Precipitator High-frequency Power Supply​

Model V0701596-001102​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -40℃ to 70℃​

Storage Temperature -55℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Rack-mounted Installation)​

Installation Method Standard 3U Rack Installation (Compatible with High-frequency Power Supply Control Cabinets)​

Compatible Power Specifications 85kV/1200mA 70kV/1700mA (ALSTOM SIR4 Series High-frequency Power Supply)​

Control Accuracy Output Voltage Regulation Accuracy ±1% Rated Value​

Communication Interfaces 1 Ethernet Port (Modbus TCP/IP) 1 RS485 Serial Port (Modbus RTU)​

Current Consumption Typical 120mA (24VDC) Maximum 180mA (24VDC)​

Size 160mm×233mm×57mm (Length×Width×Height, 3U Standard Size)​

Weight 1.2kg​

Power Consumption Typical 2.9W Maximum 4.3W​

Certification Qualification CE UL IEC 61131-3 RoHS​

Compatible System ALSTOM SIR4 Series High-frequency Power Supplies Industrial Automation Control Systems SCADA Systems Electrostatic Precipitator Control Systems​

Diagnostic Function Overvoltage/Overcurrent Protection Power Supply Abnormality Alarm Module Self-diagnosis Communication Fault Detection Equipment Status Monitoring​

Anti-interference Level Complies with EN 55032/EN 61000-6-2 Industrial EMC Standards​

MTBF (Mean Time Between Failures) ≥500,000 Hours​

Software Support Supports Software Upgrade/Downgrade Compatible with Existing Equipment Software Versions​

PRODUCT PERFORMANCE​

Compatible with two high-frequency power supply specifications (85kV/1200mA and 70kV/1700mA), no additional modification required to adapt to different power requirements, improving equipment versatility​

Strictly complies with IEC 61131-3 standard, supports industrial standard communication protocols, realizing seamless data interaction with upper control systems and simplifying system integration​

Output voltage regulation accuracy up to ±1% rated value, ensuring stable output of high-frequency power supply and improving processing efficiency in electrostatic precipitator and other application scenarios​

Industrial-grade wide-temperature design, can operate stably in the temperature range of -40℃ to 70℃ and 5%-95% non-condensing humidity environment, adapting to harsh industrial working conditions​

Integrates multiple protection and diagnostic functions such as overvoltage, overcurrent and communication fault, real-time monitoring of equipment operation status, fault information is fed back in a timely manner, reducing operation and maintenance costs​

Anti-electromagnetic interference performance complies with industrial EMC standards, capable of resisting electromagnetic interference generated during high-frequency power supply operation, ensuring the accuracy of control signal transmission​

Supports software upgrade/downgrade function, can match existing equipment software versions, facilitating later system maintenance and function upgrade​

Rack-mounted installation design, compatible with standard industrial control cabinets, easy to install and disassemble, and can be quickly integrated into existing control links​
