ALSTOM SDK-C0167-1 12004-08-01 SBS07M076B Traction control module

ALSTOM SDK-C0167-1 12004-08-01 SBS07M076B Traction control module

SPECIFIC PARAMETERS​

Brand ALSTOM​

Product Series SDK Series Industrial-grade Traction Control Modules​

Product Type High-performance High-power Traction Converter Control Module​

Model SDK-C0167-1 12004-08-01 SBS07M076B​

Channel Configuration 8-channel AI + 6-channel AO + 16-channel DI + 12-channel DO​

Analog Input 4-20mA/±10V 16-bit resolution 300Hz/channel sampling rate​

Analog Output 4-20mA/±10V 16-bit resolution ±0.03% FS output accuracy​

Digital Input 24VDC wet contacts .3ms response time​

Digital Output 24VDC/15A Supports 30kHz PWM pulse output​

Working Voltage 24VDC±15% Dual redundant power input​

Working Temperature -40℃ to 90℃​

Storage Temperature -55℃ to 105℃​

Relative Humidity 5%-95% Non-condensing​

Protection Level IP65 (Module-level)​

Installation Method Bolt-fixed Standard traction converter mounting holes​

Size 200mm×160mm×80mm (L×W×H)​

Weight 3.2kg​

Power Consumption Typical 18W Maximum 25W​

Certification CE UL EN 50121-3-2 IEC 61131-3 IEC 61508 (SIL 3)​

Compatible Systems ALSTOM MITRAC traction control system Rail transit TCMS Industrial DCS/SCADA High-power drive platform Energy storage converter system​

Diagnostic Functions Channel self-diagnosis Overcurrent/overvoltage/overheating/short-circuit alarm Motor status monitoring Communication diagnosis Power protection Module self-verification​

Anti-interference Level Complies with EN 50121-3-2/EN 61000-6-2 standards​

Vibration/Shock Resistance Complies with IEC 61373 Class 3 standard​

MTBF ≥2,200,000 hours​

Housing Material Aviation-grade high-strength aluminum alloy + metal shield Fully sealed structure​

Communication Interfaces Ethernet/IP Profibus DP CANopen Supports Modbus TCP​

Programming Environment ALSTOM Control Suite Supports IEC 61131-3 standard languages​

Clock Synchronization Supports IRIG-B/PTP Synchronization accuracy ±0.05ms​

Insulation Resistance ≥250MΩ (1000VDC)​

Channel Isolation 3500Vac electrical isolation between input/output/power​

Control Algorithms Built-in vector control/DTC/field weakening control algorithms​

PRODUCT PERFORMANCE​

Enhanced multi-channel configuration covers full-link signal requirements of traction systems, adapting to complex control logic​

16-bit resolution and ±0.03% FS accuracy, 300Hz sampling rate enables precise capture and regulation of dynamic parameters​

Three algorithms switch flexibly, balancing low-speed high torque and high-speed efficient operation, reducing energy loss​

-40℃ to 90℃ wide temperature adaptability, withstanding multiple extreme on-board working conditions​

IP65 protection and high-strength housing, providing excellent dustproof, waterproof, corrosion-resistant and vibration-resistant performance​

3500Vac high electrical isolation, resisting strong electromagnetic interference and voltage surges, ensuring signal and control stability​

Dual redundant power design, resisting power fluctuations and single power failure, ensuring uninterrupted operation​

Multi-protocol bus compatibility, supporting cross-system linkage and flexible access​

Deeply compatible with MITRAC system, simplifying integration and operation/maintenance processes​

SIL 3 safety level, four-fold protection mechanism with millisecond-level fault response, ensuring system safety​
