ALSTOM NRD108033 8RDC44667G01 SA44667.C controller module

ALSTOM NRD108033 8RDC44667G01 SA44667.C controller module

SPECIFIC PARAMETERS​

Brand ALSTOM​

Product Series NRD Series Industrial High-end Intermediate Relay Modules​

Product Type Industrial-grade Ultra-ruggedized Sealed Intermediate Relay Module​

Model NRD108033 8RDC44667G01 SA44667.C​

Working Voltage Control Voltage: 24VDC Adaptation Range: 20.4-26.4VDC​

Working Temperature -40℃ to 75℃​

Storage Temperature -55℃ to 90℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Board-mounted Installation)​

Installation Method Standard 3U Rack Slot Installation/ DIN Rail Installation (Dual Adaptation)​

Contact Configuration 10 Sets of Changeover Contacts (NO+NC)​

Contact Capacity AC: AC-15 250V 15A DC: DC-13 24V 12A​

Contact Life Mechanical Life ≥15,000,000 Cycles Electrical Life ≥200,000 Cycles (Rated Load)​

Operation Time ≤10ms (Pick-up) ≤7ms (Drop-out)​

Coil Power Consumption Typical 0.9W Maximum 1.2W​

Isolation Level 6000Vac Electrical Isolation Between Coil and Contacts 3000Vac Electrical Isolation Between Contact Groups​

Size 105mm×165mm×52mm (Length×Width×Height)​

Weight 0.9kg​

Certification Qualification CE UL IEC 60947-5-1 IEC 61131-3 RoHS TÜV IRIS​

Compatible System ALSTOM ALSPA Control Systems Industrial DCS/SCADA Core Systems Power Protection Devices Key Rail Transit TCMS Systems Steam Turbine Control Systems​

Diagnostic Functions Real-time Contact Status Monitoring Coil Overvoltage/Undervoltage Protection Module Self-diagnosis Fault Signal Feedback Circuit Short Circuit/Overload Detection Contact Wear Warning​

Anti-interference Level Complies with EN 55032/EN 61000-6-2/EN 50121-3-2 Industrial and Rail Transit EMC Standards​

Vibration and Shock Resistance Complies with IEC 61373 Class 2 (Rail Transit Grade) Standard​

MTBF (Mean Time Between Failures) ≥1,500,000 Hours​

Housing Material Flame-retardant ABS+Glass Fiber Reinforced Engineering Plastic Fully Sealed Structure​

Contact Material Silver Alloy Contacts (AgSnO₂ Alloy)​

Coil Type Ultra-low Power Sealed Coil Dual Surge-resistant Design​

Wiring Method Screw-type Terminal Blocks Anti-loosening and Anti-corrosion Design​

Insulation Resistance ≥100MΩ (500VDC)​

PRODUCT PERFORMANCE​

Adopts 10 sets of high-density changeover contacts configuration, supporting synchronous switching of multi-circuit signals and high-power load driving, adapting to complex core control links, improving system integration density and control flexibility​

High-conductivity silver alloy (AgSnO₂) contact material combined with fully sealed structure, mechanical life over 15 million cycles and electrical life over 200,000 cycles, meeting the long-term stable operation requirements in high-frequency and high-load scenarios​

6000Vac ultra-high electrical isolation between coil and contacts, 3000Vac isolation between contact groups, effectively resisting strong electromagnetic interference and high-voltage surges in industrial sites, ensuring the integrity of core control signal transmission​

Industrial-grade wide-temperature and wide-humidity adaptability, can work stably in the temperature range of -40℃ to 75℃ and 5%-95% non-condensing humidity environment, adapting to extreme working conditions such as alpine, high temperature and high humidity​

24VDC wide-range control voltage input design, compatible with power supply fluctuations in industrial sites, dual surge-resistant coil protection can resist instantaneous voltage impact and avoid module damage​

Dual installation methods for flexible adaptation, both standard 3U rack integration and independent DIN rail fixing are available, meeting the different installation needs of core control cabinets and distributed control nodes​

Built-in contact wear warning and circuit short circuit/overload detection functions, combined with a comprehensive self-diagnostic mechanism, fault location is accurate to a single contact, greatly reducing the operation and maintenance cost and downtime of core systems​

Flame-retardant ABS+glass fiber reinforced housing and fully sealed design, dustproof, moisture-proof, corrosion-resistant and anti-aging, adapting to harsh environments such as high dust and strong corrosion in industrial sites​

Extremely fast action response, pick-up time ≤10ms and drop-out time ≤7ms, meeting the millisecond-level switching needs of core control circuits and ensuring real-time and accurate execution of control commands​

Seamlessly compatible with ALSTOM’s full range of core control systems, no additional adaptation modules required, low control link delay, ensuring high reliability of core industrial processes and rail transit systems​
