ALSTOM N895609510K N895609010R E32OUT N895609100P Digital output module

ALSTOM N895609510K N895609010R E32OUT N895609100P Digital output module

SPECIFIC PARAMETERS​

Brand ALSTOM​

Product Series Industrial Digital Output Module Series​

Product Type 32-channel Industrial-grade Digital Output Module​

Model N895609510K N895609010R E32OUT N895609100P​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -40℃ to 70℃​

Storage Temperature -55℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Board-mounted Installation)​

Installation Method Standard 3U Rack Slot Installation (Compatible with ALSTOM Standard Control Backplane)​

Output Channels 32 Independent Digital Outputs (Relay Output Type)​

Output Current per Channel Maximum 2A per Channel Total Module Output Current ≤16A​

Isolation Level 2500Vdc Electrical Isolation Between Channels/Channels and Backplane​

Communication Interfaces 1 Ethernet Port (TCP/IP) 2 RS485 Serial Ports (Modbus RTU)​

Current Consumption Typical 250mA (24VDC) Maximum 350mA (24VDC)​

Size 160mm×233mm×57mm (Length×Width×Height, 3U Standard Size)​

Weight 1.3kg​

Power Consumption Typical 6.0W Maximum 8.4W​

Certification Qualification CE UL IEC 61131-3 RoHS​

Compatible System ALSTOM ALSPA Control Systems Industrial DCS/SCADA Systems Rail Transit TCMS Systems Industrial Automation Control Platforms​

Diagnostic Functions Channel Overcurrent Protection Overvoltage Protection Channel Short Circuit Detection Module Self-diagnosis Output Status Monitoring Fault Alarm Feedback​

Anti-interference Level Complies with EN 55032/EN 61000-6-2 Industrial EMC Standards​

Vibration and Shock Resistance Complies with IEC 61373 Class 1 Standard​

MTBF (Mean Time Between Failures) ≥600,000 Hours​

PCB Process Ruggedized FR-4 Material Multi-layer Wiring Independent Channel Shielding Design​

PRODUCT PERFORMANCE​

Adopts 32-channel high-density integration design, significantly saving installation space in control cabinets, reducing system wiring complexity and improving control link integration efficiency​

Each channel is equipped with 2500Vdc independent electrical isolation, effectively avoiding signal interference between channels and ensuring the stability of output signals and the safety of equipment operation​

Supports maximum output current of 2A per channel, which can directly drive industrial actuators such as solenoid valves, contactors and indicator lights without intermediate amplification modules​

Integrates overcurrent, overvoltage and short circuit triple protection mechanisms, quickly cutting off output channels under abnormal working conditions to protect the module and downstream equipment from damage​

Industrial-grade wide-temperature adaptability, can work stably for a long time in the temperature range of -40℃ to 70℃ and 5%-95% non-condensing humidity environment, adapting to extreme industrial scenarios​

Modular plug-in structure design, easy to install and disassemble, supporting online maintenance and replacement, reducing system downtime and improving equipment availability​

Compatible with industrial standard communication protocols such as Modbus and Ethernet, realizing real-time data interaction with upper control systems, and output status and fault information can be monitored remotely​

Seamlessly compatible with ALSTOM ALSPA series control systems, no additional adaptation software required, simplifying system integration process and ensuring fast response of control commands​

Independent channel shielding design and anti-electromagnetic interference optimization, enabling stable operation around frequency converters and high-power equipment, and signal transmission is not affected by industrial on-site interference​

Equipped with real-time output status monitoring function, combined with a comprehensive self-diagnostic mechanism, fault location is accurate, reducing operation and maintenance troubleshooting difficulty and cost​
