ALSTOM N895600512D N895600051C ECPU_1 N895600200Q Core CPU module

ALSTOM N895600512D N895600051C ECPU_1 N895600200Q Core CPU module

SPECIFIC PARAMETERS​

Brand ALSTOM​

Product Series ALSPA Series Industrial Control Core Modules​

Product Type Industrial-grade Embedded Core CPU Module​

Model N895600512D N895600051C ECPU_1 N895600200Q​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -40℃ to 70℃​

Storage Temperature -55℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Board-mounted Installation)​

Installation Method Standard 3U Rack Slot Installation (Compatible with ALSPA System Backplane)​

Processor Type Industrial-grade Embedded Microcontroller (MCU)​

Data Processing Capacity Supports Multi-task Real-time Operating System Maximum 8,000 Logic Instructions per Second​

Memory Configuration 512KB Program Memory 2MB Data Memory​

Communication Interfaces 1 Ethernet Port (TCP/IP) 2 RS485 Serial Ports (Modbus RTU) 1 Dedicated Parallel Bus (Compatible with ALSTOM Proprietary Protocol)​

Expansion Capacity Seamless Expansion with MVDI/MVDO Series I/O Modules Maximum 32 I/O Channels Supported​

Current Consumption Typical 200mA (24VDC) Maximum 280mA (24VDC)​

Size 160mm×233mm×57mm (Length×Width×Height, 3U Standard Size)​

Weight 1.3kg​

Power Consumption Typical 4.8W Maximum 6.7W​

Certification Qualification CE UL IEC 61131-3 IEC 61373 RoHS​

Compatible System ALSTOM ALSPA Control System UNITROL® Excitation System NRD108033 Series Controllers Industrial DCS/SCADA Systems​

Diagnostic Functions Module Self-diagnosis Program Operation Monitoring Communication Link Detection Power Supply Abnormality Protection I/O Module Communication Fault Alarm SOE Event Recording (1ms Resolution)​

Anti-interference Level Complies with EN 55032/EN 61000-6-2 Industrial EMC Standards​

Vibration and Shock Resistance Complies with IEC 61373 Class 1 Standard​

MTBF (Mean Time Between Failures) ≥600,000 Hours​

PCB Process Ruggedized FR-4 Material Multi-layer Wiring Differential Amplification Design for Key Signals​

PRODUCT PERFORMANCE​

Adopts industrial-grade embedded microcontroller with a data processing capacity of 8,000 logic instructions per second, providing high-speed real-time computing capability to ensure the accurate execution of complex control algorithms​

Seamlessly compatible with ALSTOM ALSPA control system and UNITROL® excitation system, can directly interconnect with NRD108033 controllers and MVDI/MVDO series I/O modules without additional adaptation modules​

Ruggedized hardware architecture and differential amplification design for key signals, anti-electromagnetic interference performance complies with industrial EMC standards, enabling stable operation around frequency converters and high-power equipment​

Industrial-grade wide-temperature adaptability, can work stably for a long time in the temperature range of -40℃ to 70℃ and 5%-95% non-condensing humidity environment, adapting to extreme industrial working conditions​

Supports multi-protocol communication and dedicated parallel bus, realizing low-latency data interaction with upper systems and sub-modules, ensuring fast response of control commands and integrity of data transmission​

Built-in comprehensive self-diagnostic and fault protection mechanisms, 1ms resolution SOE event recording can accurately trace faults, and information such as power supply abnormalities and communication faults is fed back in real time to facilitate rapid troubleshooting​

Modular plug-in design, compatible with ALSTOM standard racks and backplanes, easy to install and disassemble, supporting online maintenance and replacement without affecting the overall operation of the system​

Sufficient program memory and data memory configuration, supporting complex control logic programming and local storage of key data, meeting the core control needs of industrial automation and excitation systems​
