ALSTOM N895314513L Auxiliary control module

ALSTOM N895314513L Auxiliary control module

SPECIFIC PARAMETERS​

Brand ALSTOM​

Product Series N Series Industrial-grade Rail Transit Auxiliary Control Modules​

Product Type Special Control Module for Rail Transit Auxiliary Systems​

Model N895314513L​

Channel Configuration 4-channel AI + 4-channel AO + 10-channel DI + 6-channel DO​

Analog Input 4-20mA/±10V 16-bit resolution 200Hz/channel sampling rate​

Analog Output 4-20mA/±10V 16-bit resolution ±0.05% FS output accuracy​

Digital Input 24VDC wet contacts .5ms response time​

Digital Output 24VDC/10A Supports 20kHz PWM pulse output​

Working Voltage 24VDC±15% Dual redundant power input​

Working Temperature -40℃ to 85℃​

Storage Temperature -55℃ to 100℃​

Relative Humidity 5%-95% Non-condensing​

Protection Level IP65 (Module-level)​

Installation Method Bolt-fixed Standard auxiliary control cabinet mounting holes​

Size 160mm×140mm×70mm (L×W×H)​

Weight 2.5kg​

Power Consumption Typical 12W Maximum 18W​

Certification CE UL EN 50121-3-2 IEC 61131-3 IEC 61508 (SIL 3)​

Compatible Systems ALSTOM MITRAC control system Rail transit TCMS Industrial DCS/SCADA Auxiliary drive control system Vehicle auxiliary power system​

Diagnostic Functions Channel fault self-diagnosis Overcurrent/overvoltage/overheating alarm Equipment status monitoring Communication link diagnosis Power protection​

Anti-interference Level Complies with EN 50121-3-2/EN 61000-6-2 standards​

Vibration/Shock Resistance Complies with IEC 61373 Class 3 standard (Rail transit grade)​

MTBF ≥1,800,000 hours​

Housing Material Aviation-grade aluminum alloy + metal shield Fully sealed structure​

Communication Interfaces Ethernet/IP Profibus DP CANopen Supports Modbus TCP​

Programming Environment ALSTOM Control Suite Supports IEC 61131-3 standard languages​

Clock Synchronization Supports IRIG-B/PTP Synchronization accuracy ±0.1ms​

Insulation Resistance ≥200MΩ (1000VDC)​

Channel Isolation 3000Vac electrical isolation between input/output/power​

PRODUCT PERFORMANCE​

Multi-channel configuration covers full requirements of auxiliary system signal acquisition and control, adapting to complex auxiliary working condition logic​

16-bit resolution and ±0.05% FS accuracy, 200Hz sampling rate enables precise capture and regulation of parameters​

-40℃ to 85℃ wide temperature adaptability, withstanding on-board high temperature, alpine, high humidity and strong electromagnetic environment​

IP65 fully sealed protection and aluminum alloy housing, providing excellent dustproof, waterproof, corrosion-resistant and vibration-resistant performance​

3000Vac high electrical isolation, resisting strong electromagnetic interference and voltage surges, ensuring signal and control stability​

Dual redundant power design, resisting power fluctuations and single power failure, ensuring uninterrupted module operation​

Multi-protocol bus compatibility, supporting cross-system linkage and flexible access to various control platforms​

Deeply compatible with MITRAC system, simplifying integration, debugging and later operation/maintenance processes​

SIL 3 safety level, multiple protection mechanisms with millisecond-level fault response, ensuring auxiliary system safety​
