ALSTOM N895313512X N95313012D SUP-AL N895313000R Power Supply and System Support Module
SPECIFIC PARAMETERS
Brand ALSTOM
Product Series SUP-AL Series Power Supply and System Support Modules
Product Type Industrial-grade Multi-channel Power Output and Signal Support Module
Model N895313512X N95313012D SUP-AL N895313000R
Working Voltage Input: 24VDC±10% Output: 5VDC/12VDC/24VDC (Three Independent Regulated Outputs)
Working Temperature -40℃ to 70℃
Storage Temperature -55℃ to 85℃
Relative Humidity 5% to 95% Non-condensing (No Dew Formation)
Protection Level IP20 (Board-mounted Installation)
Installation Method Standard 3U Rack Slot Installation (Compatible with ALSTOM Standard Control Backplane)
Power Output 5VDC (4A) 12VDC (3A) 24VDC (2A) Three Independent Outputs, Ripple ≤100mVp-p
Signal Interfaces 8 Signal Isolation Transfer Channels 4 RS485 Signal Amplification Interfaces
Isolation Level 2500Vdc Electrical Isolation Between Power Outputs/Signal Channels
Communication Interfaces 1 Ethernet Port (TCP/IP) 2 RS485 Serial Ports (Modbus RTU)
Current Consumption Typical 380mA (Input 24VDC) Maximum 500mA (Input 24VDC)
Size 160mm×233mm×57mm (Length×Width×Height, 3U Standard Size)
Weight 1.4kg
Power Consumption Typical 9.1W Maximum 12.0W
Certification Qualification CE UL IEC 61131-3 IEC 61373 RoHS
Compatible System ALSTOM Mark VI/Vie Control Systems Industrial DCS/SCADA Systems Rail Transit TCMS Systems Industrial Control Terminal Equipment
Diagnostic Functions Overvoltage/Overcurrent/Over-temperature Protection Undervoltage Alarm Signal Short Circuit Detection Module Self-diagnosis Output Voltage Monitoring
Anti-interference Level Complies with EN 55032/EN 61000-6-2/EN 61000-6-4 Industrial EMC Standards
Vibration and Shock Resistance Complies with IEC 61373 Class 1 Standard
MTBF (Mean Time Between Failures) ≥600,000 Hours
PCB Process Ruggedized FR-4 Material Multi-layer Wiring Anti-corrosion Coating Treatment
PRODUCT PERFORMANCE
Adopts high-precision power management chip and voltage stabilization circuit design, the ripple of three independent output voltages is ≤100mVp-p, with strong power supply stability, ensuring the precise operation of control modules, sensors and other equipment
2500Vdc high electrical isolation design, effectively isolating electromagnetic interference and ground loop risks in industrial sites, ensuring the purity of power output and the integrity of signal transmission
Industrial-grade wide-temperature adaptability, can work stably for a long time in the temperature range of -40℃ to 70℃ and 5%-95% non-condensing humidity environment, adapting to extreme industrial working conditions
Integrates overvoltage, overcurrent and over-temperature triple protection mechanisms, real-time monitoring of power output status, quickly cutting off power supply in abnormal situations to protect the safety of downstream equipment
Supports 8-channel signal isolation transfer and 4-channel RS485 signal amplification functions, which can extend signal transmission distance, enhance the anti-interference ability of weak signals, and adapt to complex control link layouts
Compatible with industrial standard protocols such as Modbus and Ethernet, realizing real-time data interaction with upper control systems, and power status and fault information can be monitored remotely
Ruggedized PCB and anti-corrosion coating treatment, combined with the selection of high-reliability components, vibration and shock resistance complies with IEC 61373 Class 1 standard, adapting to harsh installation environments
3U standard size design, compatible with ALSTOM standard control cabinets and backplanes, easy to install and disassemble, can be quickly integrated into existing control systems, simplifying system expansion and maintenance
Equipped with real-time output voltage monitoring function, which can accurately feed back the power supply status, and with a comprehensive self-diagnostic mechanism, fault location is fast and accurate, reducing operation and maintenance costs
