ALSTOM MBCI01N1AB0761B Communication and Control Interface Module

ALSTOM MBCI01N1AB0761B Communication and Control Interface Module

Specific Parameters

Brand ALSTOM

Product Series MICOM Relay Protection & Automation Series

Product Type Industrial-Grade Communication & Control Interface Module, Interface Unit for Relay Protection

Model ALSTOM MBCI01N1AB0761B

Country of Origin France

Compatible Devices MICOM Series Relay Protection Devices, Advant Controller Series Racks

Operating Power Supply Dual-mode Compatible: 24VDC / 110–250VAC

Rated Power Consumption Less Than 7W

Input/Output Signals Supports Analog Signals (4-20mA) and Digital Signals

Communication Protocols IEC 61850, Modbus RTU/TCP, DNP3.0, IEC 60870-5-103

Communication Interfaces Ethernet Port, RS485 Serial Interface, RS232 Configuration Interface

Isolation Voltage 2500VAC between channels, 3000VAC channel to ground

Operating Temperature Range -40℃ to +70℃

Storage Temperature Range -40℃ to +85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Level IP20

Physical Dimensions 145mm×90mm×22mm (Length×Width×Height)

Physical Weight Approximately 0.18kg

Mounting Method Standard Rail Mounting, Built-in Slot Mounting for Protection Devices

Special Functions Supports Hot-Swapping, Real-Time Diagnosis, Event Recording, Fault Location Indication

Certification Standards IEC 60255, IEC 61850, CE, UL

Warranty Period 12 Months

Product Performance

Compatible with MICOM series relay protection devices and Advant Controller series racks, adopting dual-mode compatible power supply of 24VDC/110–250VAC, with a rated power consumption of less than 7W, it is energy-saving and efficient, can adapt to the 24-hour uninterrupted operation needs of various power systems worldwide, and has high operational stability.

Supports the input and output processing of analog signals (4-20mA) and digital signals, has high-precision signal conditioning and conversion functions, can accurately collect and process power equipment operating parameters, and meet the core needs of relay protection and remote control in power systems.

Equipped with multiple communication interfaces including Ethernet, RS485 and RS232, supports mainstream power communication protocols such as IEC 61850 and Modbus RTU/TCP, and can be seamlessly integrated into existing substation automation systems and SCADA systems to realize real-time data interaction and remote monitoring.

Possesses high-level electrical isolation performance, with 2500VAC isolation voltage between channels and 3000VAC isolation voltage between channels and ground, which can effectively block ground loop interference and on-site strong electromagnetic interference, ensuring the stability and integrity of communication signals and control commands.

With a protection level of IP20, it has excellent dustproof performance, which can effectively protect internal circuits from industrial dust. Combined with industrial-grade reinforced packaging, it extends the service life of the module and adapts to harsh industrial environments such as substations.

The operating temperature covers -40℃ to +70℃, and the storage temperature range is -40℃ to +85℃. It can operate stably in extreme high and low temperature environments, adapt to temperature fluctuations in alpine, high-temperature and outdoor power industrial environments, and has no shutdown hidden dangers.

Supports hot-swapping function, which can complete the disassembly and replacement of the module while the system is powered on and running, without interrupting the operation of the entire power protection system, greatly improving equipment maintenance efficiency and reducing unplanned downtime.

Integrated with complete real-time diagnosis, event recording and fault location functions, it can real-time monitor the module operation status, communication links and signal quality, quickly locate fault points, facilitate staff to check and handle in a timely manner, and reduce maintenance costs.

Adopting standardized modular design, supporting standard rail and built-in slot mounting for protection devices, it is easy to install, can be directly integrated into existing power protection systems without additional adaptation and debugging, consistent with ALSTOM’s modular design concept.

Complies with international power industry standards such as IEC 60255 and IEC 61850, as well as CE and UL certification requirements. The product quality and safety performance meet the specifications of the global power system protection and communication field, with high operational reliability.
