ALSTOM 730475-D ELEMENTS-F2 controller module

ALSTOM 730475-D ELEMENTS-F2 controller module

SPECIFIC PARAMETERS​

Brand ALSTOM​

Product Series ELEMENTS Series Industrial Control Modules​

Product Type Turbine-specific Control Module​

Model 730475-D ELEMENTS-F2​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -40℃ to 70℃​

Storage Temperature -55℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Rack-mounted Installation)​

Installation Method Standard 3U Rack Installation (Compatible with Industrial Control Cabinets)​

Control Functions First Trip Indication Critical Speed Avoidance Automatic Start Sequence Dual-speed Load Dynamics Zero Speed Detection Peak Speed Indication Overspeed Trip Isochronous Load Sharing​

Communication Interfaces Supports Modbus Protocol PROFINET Protocol Ethernet Protocol Multiple Types of Industrial Communication Interfaces​

Input/Output 5 Trip Inputs 2 Speed Band Control Outputs Multiple Analog Inputs/Outputs Digital Inputs/Outputs​

Operating Modes Programming Mode Operation Mode Service Mode​

Current Consumption Typical 180mA (24VDC) Maximum 250mA (24VDC)​

Size 160mm×233mm×57mm (Length×Width×Height, 3U Standard Size)​

Weight 1.2kg​

Power Consumption Typical 4.3W Maximum 6.0W​

Certification Qualification CE Complies with IEC 61131-3 Standard​

Compatible System ALSTOM Industrial Automation Systems Turbine Control Platforms Industrial DCS/SCADA Systems Power Equipment Monitoring Systems​

Diagnostic Functions Module Self-diagnosis Fault Status Feedback Overspeed Alarm Power Supply Abnormality Protection Signal Transmission Verification​

Anti-interference Level Complies with EN 55032/EN 61000-6-2 Industrial EMC Standards​

MTBF (Mean Time Between Failures) ≥500,000 Hours​

PRODUCT PERFORMANCE​

Adopts modular design concept, compact structure and flexible configuration, can customize functions according to different turbine application scenarios, adapting to various types of turbines such as single-stage extraction back-pressure and suction type​

Integrates core control functions such as first trip indication and critical speed avoidance, supports hot and cold automatic start sequences, meeting the full-life cycle operation control needs of power equipment​

Equipped with dual-speed load dynamic adjustment and isochronous load sharing capabilities, enabling coordinated operation of multiple units, improving the overall operational efficiency and stability of the power system​

Supports multiple industrial standard communication protocols, enabling seamless interconnection with upper control systems and on-site equipment, with low data transmission delay and timely response to control commands​

Industrial-grade wide-temperature operating range and high humidity adaptability, can work stably for a long time in the environment of -40℃ to 70℃ and 5%-95% non-condensing, adapting to harsh industrial working conditions​

Uses high-reliability industrial-grade components, anti-electromagnetic interference performance complies with industrial EMC standards, effectively resisting interference in industrial sites, ensuring the accuracy of control signal transmission and module operation stability​

Built-in comprehensive fault diagnosis and protection mechanisms, real-time monitoring of equipment operation status, faults such as overspeed trip and power supply abnormality can be quickly responded to and fed back, reducing equipment operation risks​

Three operating modes can be flexibly switched, programming mode is used for function configuration, operation mode realizes full-process control, and service mode enhances system operation convenience during unit operation​

Compatible with ALSTOM industrial automation systems and third-party control platforms, enabling rapid integration without additional adaptation modules, simplifying system deployment and maintenance processes​
