Allen Bradley SLC500 1746-NIO4V High Resolution Analog Combination Module

Allen Bradley SLC500 1746-NIO4V High Resolution Analog Combination Module

    The Allen-Bradley 1746-NIO4V is a high-resolution analog combination module designed for industrial automation applications. It provides reliable data acquisition and control, featuring both input and output channels for a wide range of applications.

Model Type:SLC500

Model Number:1746-NIO4V

Manufacturer:Allen Bradley

Module Type:Analog Combination Module

Number Of Channels:2 (Input), 2 (Output)

Common Mode Voltage Range:-20 To 20 V

Absolute Input Voltage:Plus/Minus 7.5 VDC or 7.5 VAC RMS (Maximum)

Input Range:-20 To 20 mA

Absolute Input Current:-30 To 30 mA (Maximum)

Output Range:-10 To 10 V – 1 LSB

Full Scale Output:10 VDC

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Current Rating:Backplane Current Draw: 55 mA

    The Allen-Bradley 1746-NIO4V Analog Combination Module is designed to offer high resolution and reliability for industrial automation applications. This module provides 2 input channels and 2 output channels, ensuring accurate data acquisition and control. Its high common mode voltage range (-20 to 20 V) allows for a wide variety of input signals, making it suitable for various industrial processes. With overvoltage protection up to 7.5 VAC RMS, this module offers robust performance in demanding environments. Additionally, its compact design makes installation straightforward and efficient, saving valuable space in control panels. The 1746-NIO4V is a versatile solution for engineers looking to enhance their automation systems with reliable analog signal handling capabilities.
