Allen-Bradley 845T-HB13PCB1Size 20 Frame Incremental Encoder
The Allen Bradley 845T-HB13PCB1 Size 20 Frame Incremental Encoder is designed for precise position feedback in various industrial applications. It offers robust performance, reliability, and durability under challenging conditions.
Model Number:845T-HB13PCB1Size 20
Type:Incremental Encoder
Frame Size:20
Resolution:5000 lines per revolution
Output Signal:Square wave, 5V TTL compatible
Shaft Diameter:8mm
Shaft Length:20mm
Shaft Material:Stainless Steel
Operating Temperature Range:-20°C to +85°C
Protection Rating:IP65
Weight:150g
Dimensions:40mm x 30mm x 35mm
This Rockwell Automation 845T-HB13PCB1 incremental encoder is designed for demanding industrial environments, providing robust and reliable performance. Its high resolution of 5000 cycles per revolution ensures precise measurement of mechanical movement, which is crucial for maintaining accuracy in automated systems.
The encoder features a compact design with a frame size of 20, making it suitable for a wide range of applications where space is limited. With an operating voltage range from 10V to 30VDC, it can be easily integrated into existing electrical systems without requiring additional power supplies.
The shaft sealing mechanism with double lip sealed bearings ensures long-lasting durability even under harsh conditions, protecting the internal components from dust, moisture, and other contaminants.
Installation is straightforward thanks to its simple push-pull output signal type, allowing for quick setup and minimal downtime during maintenance. The encoder’s lightweight design at just 0.35kg makes it easy to mount on various types of machinery.
With dimensions of 70mm x 50mm x 30mm, this incremental encoder fits seamlessly into existing machinery setups, providing a seamless upgrade path for older models or systems needing enhanced precision.
