Allen-Bradley 845G-S3B8HP8192R Single-Turn Feedback Absolute Encoder, Industrial Control Solutions
The A-B 845G-S3B8HP8192R Single-Turn Feedback Absolute Encoder is a high-precision industrial device designed for accurate measurement and feedback in control systems. It is ideal for applications requiring precise position sensing, such as robotics, manufacturing machinery, and automated assembly lines.
Manufacturer:Allen Bradley
Model:845G-S3B8HP8192R
Type:Single-Turn Feedback Absolute Encoder
Resolution:8192 pulses per revolution
Operating Voltage:9-30 VDC
Output Signal:RS422, SSI
Accuracy:+/- 40 arc-minutes
Shaft Diameter:6mm
Shaft Material:Stainless Steel
Environmental Protection Rating:IP67
Weight:0.5 kg
The A-B 845G-S3B8HP8192R Single-Turn Feedback Absolute Encoder is engineered to provide precise measurements of mechanical position, making it an essential component in industrial automation systems. It offers an impressive resolution of 8192 lines per revolution, ensuring high accuracy in position sensing.
This encoder is built with robust materials to withstand the rigors of industrial environments, featuring an IP65 rating which guarantees protection against dust and water ingress. Its single-turn feedback design ensures that even in environments with limited space, the encoder can deliver precise position information without the need for complex installation.
The encoder operates within a wide temperature range from -20°C to +85°C, making it suitable for use in a variety of industrial settings. Its digital pulse output makes integration with control systems straightforward, enhancing system efficiency and reliability.
Installation of the A-B 845G-S3B8HP8192R is simple and efficient, thanks to its compact design. With a diameter of 40 mm and a length of 50 mm, it can easily be integrated into existing machinery, reducing downtime and increasing productivity.
To ensure optimal performance, this encoder is powered by a stable 5 VDC supply voltage, with a tolerance of ±10%. This power requirement allows for seamless operation with standard industrial control systems, minimizing the need for additional power conditioning equipment.
