ABB XVC770BE101 3BHE021083R0101 Digital input/output module

ABB XVC770BE101 3BHE021083R0101 Digital input/output module

Specific Parameters​

• Number of input channels: 16 digital inputs​
• Number of output channels: 16 digital outputs​
• Input voltage range: 24V DC (19.2V – 30V)​
• Output voltage range: 24V DC (19.2V – 30V)​
• Output current: Max 0.5A per channel, max total current 4A​
• Response time: Input response ≤1ms, output response ≤1ms​
• Operating temperature range: -25°C to +60°C​
• Storage temperature range: -40°C to +85°C​
• Protection class: IP20 (installed in control cabinet)​
• Isolation method: Electrical isolation between channels, isolation voltage 2500V AC​
• Dimensions: 45mm (W) × 160mm (H) × 110mm (D)​
• Weight: Approximately 350g​
• Communication interface: Supports PROFINET industrial Ethernet protocol​

Product Performance​

• High-speed signal processing: Both input and output response times are ≤1ms, enabling real-time processing of rapid signal changes in industrial fields and meeting high real-time control requirements.​
• Reliable electrical isolation: 2500V AC electrical isolation between channels effectively resists electromagnetic interference in industrial environments, ensuring the accuracy of signal transmission.​
• Stable operation in wide temperature range: Operating temperature range of -25°C to +60°C adapts to high and low temperature industrial environments, ensuring stable performance of the module under extreme temperatures.​
• Overload protection function: Output channels are equipped with overload and short-circuit protection, which automatically cut off the output when abnormal loads occur, protecting the module and connected equipment.​
• Efficient communication integration: Supports PROFINET protocol, enabling high-speed data interaction with the control system, facilitating system integration and centralized monitoring.​
