ABB XVC768115 3BHB007211R115 Digital Input/Output (DIO) module
Specific Parameters
Electrical Parameters
Operating Voltage 24VDC, supporting stable input without fluctuationCommunication Protocols Compatible with Ethernet, serial communication, Profibus and other mainstream industrial protocolsCommunication Interfaces Equipped with Ethernet interface and serial communication interface, supporting multi-device interconnectionI/O Points 16 digital input channels and 16 digital output channelsOutput Voltage 24VDC, consistent with input voltageMaximum Output Current 2A, adapting to various terminal control equipmentProtection Features Built-in overvoltage protection, short circuit protection and reverse polarity protectionCertification Standards Compliant with CE, UL and relevant standards for industrial automation equipment
Mechanical Parameters
Overall Dimensions 170mm×105mm×32mm, compact and lightweight structureWeight Approximately 120g, facilitating installation and deploymentMounting Method 35mm DIN rail mounting, compatible with standard control cabinet layoutHousing Material High-quality industrial-grade material with good insulation and mechanical strengthConnection Methods Plug-in terminals and industrial dedicated connectorsProtection Rating IP20, suitable for indoor control cabinet installation scenariosStatus Indication Equipped with power, operation, communication and fault status indicator lights
Environmental Parameters
Operating Temperature -20℃ to 60℃, no performance derating over the entire temperature rangeStorage Temperature -40℃ to 85℃, meeting extreme storage and transportation requirementsRelative Humidity ≤95% (non-condensing), suitable for high-humidity industrial scenariosVibration Resistance Complies with industrial standards, withstanding conventional installation and operation vibrationsShock Resistance Withstands mechanical shocks during transportation and installation, with stable performanceEMC Compliance Excellent anti-external electromagnetic interference capability, adapting to complex industrial electromagnetic environments
Product Performance
Rich channel configuration: 16 input and 16 output digital channels to meet multi-device connection needsStable and reliable power supply: 24VDC standard voltage input, adapting to general industrial power supply environmentsStrong integration compatibility: Seamlessly connects with ABB Symphony Plus DCS system and ACS880 frequency convertersConvenient installation and maintenance: Modular and plug-and-play design reduces disassembly, assembly and upgrade costsHigh operational reliability: Manufactured with high-quality components to ensure long-term continuous operation without faultsTimely control response: Fast signal transmission and processing capabilities to meet real-time control needsComprehensive protection mechanism: Multiple electrical protection functions to avoid equipment damage from overload or failurePractical diagnostic functions: Status indicator lights and remote diagnosis support simplify fault troubleshooting
