ABB UFC760BE42 3BHE004573R1042 High performance control module

ABB UFC760BE42 3BHE004573R1042 High performance control module

Specific Parameters​

Electrical Parameters​

Operating Voltage: 24V DC, compatible with industrial standard power supply systems​

Auxiliary Power Supply: Rated voltage 80%-120%, rated frequency 90%-110%​

Processor: Dual-core ARM Cortex A9, 1GHz clock speed, supporting parallel data processing​

Communication Interfaces: PROFIBUS DP, Profinet, EtherNet/IP, Modbus, compatible with mainstream industrial networks​

Communication Speed: Maximum 12Mbps, ensuring high-speed data transmission​

I/O Points: 64 points, supporting analog and digital signal processing​

Accuracy Class: 0.2%F·S (full scale), meeting high-precision control requirements​

Response Time: <400ms, realizing fast dynamic adjustment​

Output Ripple: <0.4% (peak-to-peak), ensuring stable output signal​

Input Power Consumption: Current <0.2VA, voltage <0.1VA, low-power design​

Protection Functions: Integrated overvoltage, overcurrent, overtemperature and overload protection, automatically cutting off output in case of faults​

Certification Standards: Compliant with CE, IEC 866, ANSI C37.90a industrial safety and EMC standards​

Mechanical Parameters​

Overall Dimensions: 120mm (L) × 80mm (W) × 40mm (D), compact modular design​

Weight: Approximately 200g, lightweight for dense installation​

Mounting Method: 35mm DIN rail mounting, adapting to standard control cabinet layout​

Housing Material: Industrial-grade flame-retardant engineering plastic, impact and corrosion resistant​

Connection Method: Screw-type terminal blocks, compatible with ≤2.5mm² wires​

Protection Rating: IP20, suitable for installation inside control cabinets​

Status Indication: Three-color LED indicators for operation, fault and communication, providing intuitive device status feedback​

Environmental Parameters​

Operating Temperature: -20℃ to +70℃, operation without derating​

Storage Temperature: -40℃ to +85℃, meeting extreme storage and transportation requirements​

Relative Humidity: 5% to 95% (non-condensing), suitable for high-humidity industrial scenarios​

EMC Compliance: Meets EN 55014-1 emission limits, withstanding 5kV 1.2/50us pulse voltage​

Long-term Stability: ≤±0.2%/year, no cumulative error​

Temperature Influence: ≤100ppm/℃, adapting to wide-temperature working conditions​

Magnetic Field Influence: Error <0.05% under 0.4KA/m magnetic field intensity change​

Product Performance​

Excellent control precision: 0.2%F·S accuracy class and low ripple output ensure stable control of excitation current and voltage​

Strong computing capability: 1GHz dual-core processor supports complex logic operations and multi-task parallel processing with outstanding efficiency​

Wide communication compatibility: Multi-protocol support enables seamless integration with DCS, frequency converters and intelligent instruments, reducing adaptation costs​

Excellent environmental adaptability: Wide-temperature operation from -20℃ to +70℃, resistant to magnetic field and electromagnetic interference, adapting to harsh industrial environments​

High operational stability: Industrial-grade components and multiple protection designs, Mean Time Between Failures (MTBF) ≥200,000 hours​

High debugging convenience: Supports remote configuration and intelligent instrument calibration, fault self-diagnosis function shortens troubleshooting time​

Flexible expandability: Modular design allows I/O point expansion, meeting the needs of control systems of different scales​
