Specific Parameters​

Core and Function Parameters​

Product Type 8-channel High-precision Isolated Analog Input Module​

Manufacturer ABB​

Model UBC717AE01, Part Number HIEE300927R0101​

Series AC 800M Series​

Input Channels 8 independent isolated analog input channels (each channel independently configurable)​

Supported Signal Types Voltage (0-10V, ±10V), Current (4-20mA, 0-20mA), Thermocouple (J/K/T/E/R/S/B/N), RTD (Pt100/Pt1000, Ni100/Ni1000)​

Signal Conditioning Built-in signal amplification, filtering, linearization compensation functions​

Compatible Systems ABB AC 800M DCS System, ABB Advant OCS System​

Communication Interface Backplane Bus (high-speed interconnection with AC 800M controller)​

Protection Functions Input Over-voltage Protection (≤36V DC), Short-circuit Protection (self-recovery), ESD Protection (±15kV)​

Diagnostic Functions Channel Open/Short Circuit Diagnosis, Signal Over-range Diagnosis, Power Fault Diagnosis, Module Overheating Diagnosis​

Installation Method AC 800M Controller 3U Rack Slot Installation​

Certification Standards CE, UL, CSA, IEC 61131-2, RoHS, ATEX, IECEx​

Status Indication Power Normal (Green LED), Channel Signal Normal (Yellow LED), Fault Alarm (Red LED)​

Electrical and Performance Parameters​

Power Supply Voltage 24V DC (19.2-28.8V DC wide-range compatible)​

Measurement Accuracy Voltage/Current Signals: ±0.05% full scale; Thermocouple/RTD: ±0.1% full scale (at 25°C)​

Resolution 24-bit ADC Conversion​

Sampling Rate 10Hz-100Hz (configurable, maximum 100Hz per channel)​

Isolation Level Inter-channel isolation voltage 250V AC, 3-way isolation (input-output-power) 1500V AC/1min​

Input Impedance Voltage Signals: ≥10MΩ; Current Signals: ≤100Ω; RTD Signals: ≤1Ω​

Common Mode Rejection Ratio ≥90dB (50/60Hz)​

Power Consumption Typical 4W, Maximum 6W​

Drift Characteristics Zero Drift ≤0.005% full scale/°C, Gain Drift ≤0.005% full scale/°C​

Physical and Environmental Parameters​

Overall Dimensions 100mm×220mm×80mm (L×W×H)​

Weight Approximately 0.8kg​

Operating Temperature Range -25°C to 70°C​

Storage Temperature Range -40°C to 85°C​

Relative Humidity 5%-95% (non-condensing, no dew)​

Protection Rating IP20 (per IEC 60529)​

Housing Material Flame-retardant ABS Plastic (UL94 V-0 Grade)​

Vibration Resistance 10-500Hz, 1.5G (30min per X/Y/Z axis)​

Shock Resistance 25G (11ms, 3 times per X/Y/Z axis)​

Product Performance​

24-bit high-resolution ADC combined with ±0.05% full scale measurement accuracy, ensuring extremely high signal acquisition accuracy to meet high-precision control requirements​

8-channel independent isolation design, supporting integrated acquisition of multiple types of analog signals, adapting to diverse signal needs in industrial fields​

3-way electrical isolation and high common mode rejection ratio, effectively resisting industrial electromagnetic interference and signal crosstalk with strong transmission stability​

Built-in signal conditioning and linearization compensation functions, adapting to thermocouple cold junction compensation and RTD lead compensation with small measurement errors​

Wide operating temperature range combined with low drift characteristics, maintaining high precision in -25°C to 70°C environment with excellent environmental adaptability​

Comprehensive fault diagnosis and multiple protection functions, enabling precise positioning of fault points to avoid damage to modules and backend equipment with high safety​

Seamless compatibility with AC 800M DCS system, supporting hot-swapping, system maintenance and expansion without shutdown, ensuring high operation and maintenance efficiency​

Configurable sampling rate, balancing acquisition speed and system resource occupation, adapting to scenarios with different response requirements​
