ABB UAD142A01 3BHE012551R0001 General control module

ABB UAD142A01 3BHE012551R0001 General control module

Specific Parameters

Brand ABB (Swiss Brand)

Product Series ABB Advant Series General Control Module

Product Type Industrial-Grade General Control Module

Model UAD142A01 3BHE012551R0001

Compatible System ABB Advant Master Distributed Control System (DCS)

Channel Configuration 16 input channels, 16 output channels, configurable as analog or digital signals

Supply Voltage 24VDC, input voltage range 18VDC to 35VDC

Operating Temperature Range -40℃ to +70℃

Storage Temperature Range -40℃ to +85℃

Relative Humidity 5% to 95%, no condensation

Protection Level IP20

Communication Protocols Supports Modbus, Profibus, Ethernet Protocols

Signal Types Adapts to Voltage, Current, Resistance, Thermocouple, RTD Signals

Installation Method DIN Rail Mounting, Screw Fixing Mounting

Physical Dimensions 70mm×99mm×60mm (Length×Width×Height)

Physical Weight 0.2kg

Isolation Voltage 2500V

Certification Standard Compliant with IEC Standard

Origin Switzerland

Product Performance

16-input and 16-output configurable channel design, compatible with both analog and digital signal types, adapting to multi-scenario signal processing needs without additional conversion modules.

Built-in signal conditioning, filtering and digital processing functions can accurately convert and optimize various input signals, providing reliable data support for control systems.

Supports multiple industrial communication protocols, enabling seamless integration into DCS systems for real-time signal transmission and remote control, improving system integration efficiency.

Wide temperature tolerance of -40℃ to +70℃ and strong anti-interference design can resist high temperature, low temperature, electromagnetic interference and vibration, adapting to harsh industrial environments.

Built-in self-inspection and diagnosis system can real-time monitor the module operation status, early warn potential faults, and ensure continuous and stable operation of equipment.

Robust structure and flexible installation methods adapt to different control cabinet layouts, with convenient installation and commissioning, shortening project implementation and operation and maintenance cycles.

2500V high isolation voltage design effectively ensures the safety of the module and surrounding equipment, avoiding signal crosstalk and equipment damage.

Deeply compatible with ABB Advant series DCS, no additional adaptation components are required, simplifying the system architecture and reducing integration costs.
