ABB TPPB-02 3HNA02320000101 Control processor module

ABB TPPB-02 3HNA02320000101 Control processor module

Specific Parameters

Brand ABB (ABB Group, Switzerland)

Product Series ABB Advant OCS Distributed Control System Core Component Series

Product Type Control Processor Module, Industrial Control Core Component, Original Spare Part

Model ABB TPPB-02 3HNA02320000101

Country of Origin Switzerland (Produced by ABB original factory)

Compatible Devices ABB Symphony Plus System, IndustrialIT System, Advant OCS System, Sensors, Actuators, I/O Expansion Modules, Upper Monitoring System

Processor 32-bit RISC Multi-core Processor, Main Frequency ≥800MHz

Instruction Execution Speed ≤0.05μs/Instruction (Single Core)

Program Memory 16MB

Data Memory 32MB

Cache Memory 4MB

Expansion Capacity Supports CF Card Expansion, Maximum 64GB; Supports Up to 8 I/O Sub-modules Expansion

Maximum Adaptable I/O Points 1024 Points (Digital + Analog)

Communication Interfaces Ethernet (2 pcs, Redundancy Supported), Profibus-DP (1 pc), RS485 (2 pcs)

Communication Protocols Modbus-TCP, Profinet, EtherNet/IP, ModuleBus

Communication Rate Up to 100Mbps

Redundancy Configuration Supports 1:1 Hot Standby Redundancy, Fault Switching Time ≤5ms

Supply Voltage DC 5V±5% or DC 24V±10% (Dual Power Input)

Rated Power Consumption Maximum 5W

Operating Temperature Range -25℃ to +70℃

Storage Temperature Range -40℃ to +85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Class IP20

Physical Dimensions 120mm×100mm×50mm

Physical Weight Approximately 0.5kg

Mounting Method Rack Mounting (Complies with IEC 60297 Standard)

Protection Type Anti-Electromagnetic Interference, Power Filtering, Electromagnetic Shielding, ESD Protection (±15kV)

Core Functions Data Processing, Logic Control, System Scheduling, Communication Management, Fault Diagnosis, Redundant Backup

Product Material High-Strength Aluminum Alloy Shell, Industrial-Grade Flame-Retardant Board

Customizable No

Certification Standards CE, IEC 61508, IEC 61000-4 Series

Warranty Period 12 Months

Product Performance

ABB TPPB-02 3HNA02320000101 is an original ABB module with strong adaptability. It can be seamlessly integrated into various mainstream ABB control systems, with convenient rack mounting, support for hot swapping and hot standby redundancy switching, fast replacement, and can stably realize precise operation and control of industrial processes.

Equipped with a 32-bit RISC multi-core processor, it has excellent computing performance, can process 128 control loops and 64 independent tasks at the same time, with fast instruction response, and can quickly adapt to the multi-variable control needs of complex industrial scenarios.

Adopting triple redundancy design of processor, power supply and communication, the data of main and standby modules are synchronized in real time, and the fault switching time is ≤5ms, which can effectively avoid unplanned shutdowns and ensure the uninterrupted operation of the control system.

Industrial-grade aluminum alloy packaging, strong electromagnetic shielding and anti-interference ability, excellent wide temperature adaptability, can operate stably in harsh working conditions such as high temperature, high dust and strong electromagnetic interference for a long time. It has built-in intelligent diagnosis function, which is convenient for quick fault location and reducing operation and maintenance costs.
