ABB TPMC866-11 Industrial Human Machine Interface (HMI) Controller
Specific Parameters
Electrical Parameters
Operating Voltage 24VDC (±10%), supporting stable wide-range inputDisplay Size 10.4-inch, adopting TFT color LCD screenResolution 800×600 pixels, ensuring clear image displayTouch Type 5-wire resistive touch screen, supporting single-point precise touchTouch Response Time ≤5ms, providing instant operation feedbackBrightness 350cd/m², adapting to strong and weak light environmentsCommunication Protocols Compatible with Modbus TCP/IP, Profibus DP, Ethernet/IP, OPC UACommunication Interfaces 2 Ethernet ports, 1 RS485 port, 2 USB portsProtection Features Built-in overvoltage protection, overcurrent protection, reverse polarity protectionCertification Standards Compliant with CE, UL, cUL, IEC 61131-2, IP65 protection certification
Mechanical Parameters
Overall Dimensions 285mm×225mm×55mm, compact structure suitable for on-site installationWeight Approximately 1.8kg, lightweight design facilitating deploymentMounting Method Wall-mounted, panel-mounted or bracket-mounted installation, compatible with industrial on-site layoutHousing Material Industrial-grade high-strength engineering plastic, with impact resistance and scratch-resistant performanceProtection Rating IP65, dustproof and waterproof for harsh industrial environmentsStatus Indication Equipped with power (green), operation (yellow), communication (blue) LED indicators
Environmental Parameters
Operating Temperature -10℃ to 55℃, no performance derating over the entire temperature rangeStorage Temperature -20℃ to 60℃, meeting extreme storage and transportation requirementsRelative Humidity 10% to 90% (non-condensing), suitable for high-humidity industrial scenariosVibration Resistance Complies with IEC 60068-2-6 standard, 2g acceleration at 5Hz-500Hz frequency rangeShock Resistance Complies with IEC 60068-2-27 standard, 15g acceleration (11ms duration)EMC Compliance Complies with EN 55014-1, EN 55014-2 standards, meeting anti-external electromagnetic interference requirements
Product Performance
Clear display effect: 800×600 high resolution combined with 350cd/m² high brightness, excellent visibility under strong lightSensitive operation response: ≤5ms touch response time, no delay in multi-point operation, smooth operation experienceWide communication compatibility: Multi-protocol integration design, seamlessly connecting to ABB DCS, PLC and third-party control systemsStrong environmental adaptability: IP65 protection rating + wide temperature operation, tolerating harsh working conditions such as dust, humidity and vibrationEfficient data processing: Supports real-time data recording and trend curve analysis, data storage capacity ≥1GBConvenient installation and maintenance: Multiple installation methods available, modular design simplifies fault troubleshooting and upgradingHigh operational reliability: Industrial-grade components and multiple electrical protections, Mean Time Between Failures (MTBF) ≥500,000 hoursFlexible remote access: Supports Web client and mobile terminal access, enabling off-site monitoring and operation
