ABB PU515A 3BSE032401R1 Industrial redundant power module

ABB PU515A 3BSE032401R1 Industrial redundant power module

SPECIFIC PARAMETERS​

Brand ABB​

Product Series S800 Series Industrial Power Supply Module​

Product Type Redundant Industrial Power Supply Module​

Order Number 3BSE032401R1​

Input Voltage 100-240VAC Wide Range Adaptation 50/60Hz​

Output Voltage 24VDC Accuracy ±0.8%​

Output Current Maximum 15A per Module Total Output 15A in Redundant Configuration​

Redundancy Type 1+1 Hot Redundancy Support Undisturbed Switching​

Working Temperature 0℃ to 60℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In-cabinet Installation)​

Efficiency Typical Value 93% Under Full Load Condition​

Power Factor ≥0.96 (Input Voltage 230VAC Full Load)​

Ripple and Noise ≤100mVp-p​

Protection Functions Overvoltage Protection Overcurrent Protection Short Circuit Protection Overheating Protection Reverse Polarity Protection​

Size 100mm×45mm×180mm (Standard 3U Module Size)​

Weight 0.8kg​

Power Consumption Typical 60W Maximum 75W​

Certification Qualification CE UL CSA IEC 61010-1 ATEX IECEx​

Compatible System ABB System 800xA Advant OCS S800 Series I/O Modules Controllers​

Interface Type Spring Clamp Terminal Adapt to 1.5-2.5mm² Conductors​

PRODUCT PERFORMANCE​

Supports 1+1 hot redundancy configuration, millisecond-level seamless switching to standby module when single module fails, ensuring zero interruption of system power supply​

Wide input voltage design adapts to 100-240VAC global power grid standards, can resist power grid fluctuations in industrial sites, and output accuracy is stable at ±0.8%​

Full-load efficiency up to 93%, power factor ≥0.96, low energy consumption design reduces system operation cost and heat dissipation pressure​

Equipped with five-fold protection mechanism, which can quickly respond to power supply abnormalities and effectively prevent core control components from being damaged due to overvoltage, short circuit and other faults​

Output ripple and noise ≤100mVp-p, providing low-interference pure direct current to ensure stable operation of precision electronic components​

Industrial-grade wide-temperature adaptation capability, can operate continuously and stably in the temperature range of 0℃ to 60℃, adapting to complex industrial scenarios such as high temperature and low temperature​

Modular 3U standard size design, spring clamp terminal wiring is convenient, installation and maintenance do not require professional tools, shortening working hours​

Supports hot-swapping operation, can complete module replacement without interrupting system operation, greatly reducing equipment downtime​

Compatible with ABB System 800xA and Advant OCS dual platforms, can be directly connected to existing control systems without additional adaptation components​

High-strength engineering plastic shell with anti-vibration design, can resist vibration interference in industrial sites, ensuring the stability of module structure and electrical performance​
