ABB PFXC141 3BSE029997R1 Tension control module (tension connection box)

ABB PFXC141 3BSE029997R1 Tension control module (tension connection box)

Specific Parameters

Brand ABB (ABB Group, Switzerland)

Product Series ABB Tension Control Series

Product Type Tension Control Module, Tension Junction Box, Industrial Control Component, Original Spare Part

Model ABB PFXC141 3BSE029997R1

Country of Origin Switzerland (Produced by ABB original factory)

Compatible Devices ABB PFSA Series Controllers, Third-Party Tension Sensors, Industrial Automation Control Systems

Processor 32-bit RISC Processor

Input Signals 4-channel Tension Sensor Input (±10mV/V Analog Signal), 2-channel Encoder Feedback Interface

Encoder Feedback Frequency Maximum 500kHz Pulse Frequency

Output Signals 1 Analog Output (V/mA), 1 Digital Output

Resolution 24-bit Σ-Δ ADC, Resolution up to 0.001%FS

Control Accuracy ±0.5%

Response Time 10ms

Signal-to-Noise Ratio ＞90dB

Supply Voltage 24VDC, Integrated 24V Power Output (Can Directly Drive Sensors)

Communication Interfaces PROFIBUS DP Interface, Modbus Interface

Communication Protocols PROFIBUS DP, Modbus

Operating Temperature Range -20℃ to +70℃

Storage Temperature Range -40℃ to +85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Class IP65

Physical Dimensions 200mm×150mm×100mm

Physical Weight Approximately 1kg

Mounting Method Standard DIN Rail Mounting, Plug-in Terminal Board, Easy to Maintain

Protection Type Anti-Electromagnetic Interference, Moisture-Proof, Dust-Proof, Built-in Electromagnetic Interference Filter Circuit

Core Functions Tension Signal Processing, Tension Measurement and Control, Signal Conversion, Encoder Feedback, Roll Diameter Adaptation, Inertia Compensation

Product Material Polycarbonate Shell, Industrial-Grade Flame-Retardant Circuit Board

Customizable No

Certification Standards CE, UL, EN61800-5-1

Warranty Period 12 Months

Product Performance

ABB PFXC141 3BSE029997R1 is an original ABB module with strong adaptability. It can be seamlessly integrated into ABB PFSA series controllers and various industrial automation systems, with convenient rail mounting and simple maintenance, and can stably realize high-precision tension measurement and control.

Equipped with a 32-bit RISC processor, it has fast operation speed, adopts triple closed-loop PID control algorithm, high control accuracy and fast response, can effectively compensate for tension fluctuation caused by diameter change, maintain constant tension operation, and reduce material waste.

Supports multi-channel signal processing and a variety of industrial communication protocols, can realize real-time data interaction with PLC, is compatible with ABB Control Panel 800 for quick calibration, and can form a complete tension control system with ABB drives.

Industrial-grade IP65 protection, excellent anti-electromagnetic interference, moisture-proof and dust-proof capabilities, strong wide temperature adaptability, can operate stably in harsh industrial working conditions such as high temperature, high dust and high humidity for a long time, with built-in fault self-diagnosis function, convenient for operation and maintenance.
