ABB PFSK109 YM322001-EK Communication connection module
Specific Parameters
Rated Operating Voltage 24VDC
Data Transmission Rate 100Mbps
Interface Type M12 Standard Industrial Interface
Operating Temperature Range -20℃ to +70℃
Relative Humidity 5% to 95%, Non-Condensing
Dielectric Withstand Voltage 1500VAC
Protection Class IP67
Outline Dimension 100mm×60mm×30mm
Weight Approx.0.5kg
Mounting Type Standard DIN Rail Mounting, Panel Fixed Mounting
Product Performance
High-speed Transmission Performance: Equipped with industrial-grade high-speed communication processing chip, the data transmission rate stably reaches 100Mbps, realizing high-speed and delay-free transmission of large-volume control data and monitoring data, no packet loss and no distortion in the whole data transmission process, meeting the needs of high-speed networking and real-time interaction of industrial control systems.
Connection Stability Performance: Adopts M12 standard industrial interface, the connection is tight and not loose, adapts to frequent vibration conditions in industrial sites, the docking between modules is accurate and firm, the communication link is continuously smooth, eliminating poor contact and link interruption problems, and ensuring long-term stable interconnection of the system.
Anti-interference Protection Performance: Built-in professional signal filtering, electromagnetic interference suppression and surge protection circuits, can effectively resist various interferences such as power grid harmonics, equipment start-stop impact and space electromagnetic radiation in industrial sites, completely eliminating data disorder, signal interruption and transmission lag problems, and the transmission link is stable all-weather.
Environmental Adaptability Performance: Has excellent wide-temperature range and high protection performance, the operating temperature covers -20℃ to +70℃, the protection class reaches IP67, which is dustproof, waterproof and moisture-resistant, adapting to harsh working conditions without constant temperature control such as outdoor sites, production workshops and harsh industrial control environments, trouble-free operation.
System Compatibility Performance: Perfectly adapts to ABB 800xA distributed control system, P series PLC and all PF series industrial control modules of the same series, supports seamless docking with various ABB control units, I/O modules and communication modules, completes system networking without additional debugging, and is compatible with mainstream industrial communication standards.
Link Monitoring Performance: Built-in real-time connection status monitoring unit, which can monitor the communication link status, data transmission rate and fault points throughout the whole process, quickly lock the fault point and trigger status prompt under abnormal working conditions, facilitating operation and maintenance personnel to quickly troubleshoot faults and ensure the continuous operation of the connection link.
Installation and Maintenance Performance: Supports two mounting methods: standard DIN rail quick mounting and panel fixed mounting, with clear interface identification, standardized wiring, simple wiring and debugging process; the module has a sturdy and durable structure with no vulnerable mechanical parts inside, maintenance-free daily, and module replacement without interrupting the overall system operation.
Safety Protection Performance: Complete electrical isolation between communication circuit and power supply circuit, meeting power frequency withstand voltage safety standards, effectively blocking high and low voltage signal crosstalk and circuit breakdown risks, built-in multiple protection circuits of overvoltage, overcurrent and short circuit, protecting the module itself and back-end communication equipment from damage, improving the safety level of the overall networking system.
