ABB P5EAa HENF206350R2 High performance industrial grade control module

ABB P5EAa HENF206350R2 High performance industrial grade control module

SPECIFIC PARAMETERS​

Brand ABB​

Product Series P5 Series Industrial-grade Control Module​

Product Type Programmable Logic Control Module​

Model P5EAa HENF206350R2​

Working Voltage 24VDC​

Input Voltage Range 24VDC​

Output Voltage 24VDC​

Output Current Maximum 10A​

Working Temperature -20℃ to 60℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Rail-mounted Installation)​

Installation Method 35mm DIN Rail Installation​

Control Mode PID Control (Parameters Adjustable)​

Communication Protocols Modbus TCP/IP Modbus RTU​

Communication Interfaces 1 Ethernet Port 1 RS485 Serial Port​

Input Channels Supports Analog Input Digital Input​

Output Channels Supports Analog Output Digital Output​

Size 180mm×150mm×80mm (Length×Width×Height)​

Weight 1.5kg​

Power Consumption Typical 15W Maximum 20W​

Certification Qualification CE UL CCC IEC 61010-1​

Compatible System PLC Systems DCS Systems SCADA Systems Industrial Automation Platforms​

Diagnostic Function Overcurrent Protection Short Circuit Protection Ground Fault Protection Arc Fault Protection Module Self-diagnosis​

Anti-interference Level Complies with EN 55032/EN 61000 Industrial EMC Standards​

Protection Function Overcurrent Protection Short Circuit Protection Ground Fault Protection Arc Fault Protection​

User Interface Intuitive Graphical User Interface​

Programming Support Programmable Logic Control Custom Control Schemes​

MTBF (Mean Time Between Failures) ≥300,000 Hours​

PRODUCT PERFORMANCE​

Adopts digital control technology and PID regulation algorithm with flexibly configurable parameters, realizing high-precision process control and monitoring, improving production efficiency and processing accuracy​

Modular structure design, easy to install and disassemble, supports flexible system expansion and function extension, adapting to automation needs of different scales​

24VDC stable power supply design with maximum 10A output current, can directly drive various industrial actuators to meet multi-scenario control output needs​

Integrates Ethernet and RS485 dual communication interfaces, compatible with Modbus series protocols, realizing high-speed data interaction with upper systems, PLCs and on-site equipment​

Industrial-grade rugged structure, withstanding wide temperature environment of -20℃ to 60℃ and 5%-95% non-condensing humidity, adapting to harsh industrial on-site operation​

Built-in multiple protection functions such as overcurrent, short circuit and ground fault protection, effectively preventing equipment failures and safety risks, ensuring stable system operation​

Intuitive graphical user interface and simple operation logic reduce debugging and operation and maintenance difficulty, improving operational convenience​

Supports programmable logic control, allowing custom control schemes according to specific application scenarios, adapting to diversified industrial process needs​

Module self-diagnostic function real-time monitors operating status, fault information is fed back in a timely manner, facilitating rapid problem location and reducing maintenance costs​

Compatible with mainstream PLC, DCS and SCADA systems, seamlessly integrating into existing industrial control networks, reducing integration costs​
