SPECIFIC PARAMETERS​

Brand ABB​

Product Series P3 Series High-end Process Controller​

Product Type Industrial-grade Ultra-high Performance Process Control Module​

Model P3ECa HENF315309R2​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -40℃ to 75℃​

Storage Temperature -55℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing (No Dew Formation)​

Protection Level IP20 (Rail-mounted Installation)​

Installation Method 35mm DIN Rail Installation​

Processor Quad-core Industrial-grade CPU 1.5GHz Main Frequency​

Memory Configuration 8GB DDR4 RAM 32GB eMMC Flash​

Programming Environment ABB Automation Builder (Supports Full Range of IEC 61131-3 Programming Languages + Function Block Libraries)​

Control Cycle Minimum 0.05ms​

Redundancy Support Supports Dual Hot Redundancy Configuration (Dual-machine Hot Standby + Cross Synchronization)​

Communication Interfaces 6 Gigabit Ethernet Ports (Supports TCP/IP, PROFINET, EtherNet/IP, OPC UA) 4 RS485 Serial Ports (Modbus RTU/TCP) 2 CANopen Interfaces 1 PROFIBUS DP Master Interface 1 EtherCAT Interface​

I/O Expansion Capacity Supports Up to 64 S800I/O Modules Maximum 16384 I/O Points​

Current Consumption Typical 450mA (24VDC) Maximum 650mA (24VDC)​

Size 140mm×100mm×50mm (Length×Width×Height)​

Weight 0.9kg​

Power Consumption Typical 10.8W Maximum 15.6W​

Certification Qualification CE UL CSA IEC 61010-1 IEC 61508 SIL 3 IEC 61850 IEC 61158 ISO 9001​

Compatible System ABB AC 800M Control Systems S800I/O Distributed Modules SCADA Systems MES Systems Industrial Ethernet Devices Third-party PLCs IIoT Platforms​

Diagnostic Function Support Redundancy Synchronization Status Monitoring Communication Link Quality Diagnosis I/O Module Fault Precise Location Power Supply Abnormality Early Warning Program Operation Logging Data Integrity Verification​

Anti-interference Level Complies with EN 55032/EN 61000-6-2/EN 61000-6-4 Industrial EMC Standards​

MTBF (Mean Time Between Failures) ≥450,000 Hours​

PRODUCT PERFORMANCE​

Quad-core industrial-grade CPU with 1.5GHz main frequency, combined with 8GB DDR4 RAM and 32GB eMMC Flash, has super-strong data processing capability, can run multiple sets of complex control logic simultaneously, control cycle as low as 0.05ms, achieving microsecond-level control command response​

Supports dual hot redundancy configuration, dual-machine cross-synchronizes data, fault switchover time ≤1ms and disturbance-free, ensuring continuous operation of critical control processes in ultra-large-scale systems, with system availability up to 99.999%​

Compatible with the full range of IEC 61131-3 programming languages and ABB dedicated function block libraries, realizing integrated programming of process control, logic interlock, batch control and recipe management through Automation Builder, adapting to ultra-large-scale complex scenario control needs​

Integrates 6 Gigabit Ethernet ports and multiple industrial protocol interfaces, supports OPC UA and IIoT platform access, enabling seamless interconnection and data sharing with distributed I/O, intelligent instruments, SCADA, MES systems and third-party equipment​

Industrial-grade wide-temperature design, can operate stably in the temperature range of -40℃ to 75℃ and non-condensing humidity environment of 5%-95%, adapting to extreme industrial scenarios such as alpine, high temperature, high humidity and high dust​

Supports expansion of up to 64 S800I/O modules and maximum 16384 I/O points, covering the multi-area and multi-process section centralized control needs of ultra-large-scale industrial plants​

Built-in all-round diagnostic system, real-time monitoring of redundancy synchronization status, communication link quality, I/O module working status and power supply stability, fault information accurately located to channel level, greatly reducing operation and maintenance costs​

24VDC wide-range power supply design, withstanding voltage fluctuations and transient sags, adapting to complex industrial power grid environments, ensuring continuous and stable power supply to the controller​

Complies with IEC 61508 SIL 3 highest safety level certification, can be directly applied to safety control systems in high-risk industrial scenarios to ensure the intrinsic safety of production processes​

35mm DIN rail installation and modular design, supporting hot swapping (requires system configuration support), facilitating system expansion, maintenance and component replacement, adapting to the phased construction needs of ultra-large-scale projects​

Supports remote programming, debugging, firmware upgrade and fault diagnosis, completing equipment maintenance through a secure encrypted network without on-site attendance, improving operation and maintenance efficiency​

Data transmission adopts end-to-end encryption and CRC verification mechanisms to prevent data leakage, tampering and loss, ensuring the integrity and security of control command and monitoring data transmission​
