SPECIFIC PARAMETERS​

Brand ABB​

Product Series Advant Series Industrial Communication Gateway Module​

Product Type Multi-protocol Industrial Communication Gateway Module​

Order Number HENF315118R2​

Country of Origin Switzerland​

Working Voltage 24VDC ±20%​

Working Temperature -20℃ to 60℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP65​

Installation Method DIN Rail Installation​

Processor ARM Cortex Series​

Memory Configuration 1GB RAM 8GB Flash​

Communication Protocols Modbus TCP/IP Modbus RTU Profinet Profibus-DP DNP3 Free Protocol​

Communication Interfaces 2 Gigabit Ethernet Ports 2 RS485 Serial Ports 1 USB 3.0 Port​

Data Transmission Rate 1Gbps for Ethernet Ports Maximum 115.2Kbps for Serial Ports​

I/O Interfaces 8 Digital Inputs 4 Digital Outputs 4 Analog Inputs 2 Analog Outputs​

Control Cycle Minimum 10ms Support Continuous Task/Cyclic Task Scheduling​

Redundancy Support CPU Redundancy CEX Bus Redundancy Communication Interface Redundancy​

Size 120mm×80mm×35mm​

Weight 3kg​

Power Consumption Typical 25W Maximum 35W​

Certification Qualification CE UL CSA IEC 60947-4-1 IEC 61131-3​

Compatible System ABB Advant Master DCS System 800xA SCADA Systems Third-party Industrial Automation Platforms​

SD Storage Support Data Backup and Engineering Recovery​

PRODUCT PERFORMANCE​

Supports bidirectional conversion of multiple industrial protocols, enabling seamless interconnection of devices from different brands and protocols, breaking system communication barriers​

Equipped with ARM Cortex high-performance processor, combined with 1GB RAM configuration, capable of quickly processing large-scale data and complex control logic​

Control cycle as low as 10ms, supporting continuous task and cyclic task scheduling, meeting the real-time requirements of process control and logic control​

Features triple redundancy design of CPU, CEX bus and communication interface, seamless switching in case of failure, ensuring uninterrupted system operation​

IP65 high protection level, with dustproof and waterproof capabilities, can be directly installed in harsh industrial sites without additional protection measures​

Industrial-grade wide-temperature adaptation capability, can operate stably in the temperature range of -20℃ to 60℃, adapting to high and low temperature extreme environments​

Combination of 2 gigabit Ethernet ports and 2 RS485 serial ports, taking into account high-speed network communication and traditional device access needs​

Supports SD card data backup and engineering recovery functions, meeting the data security requirements of level protection 2.0 for PLC systems​

Modular design with DIN rail installation, easy to install and maintain, can flexibly expand communication interfaces and I/O channels​

Anti-electromagnetic interference design complies with industrial EMC standards, effectively resisting on-site electromagnetic radiation and conducted interference, ensuring signal integrity​

Supports remote diagnosis and maintenance, enabling parameter configuration and fault troubleshooting through the network, reducing system operation and maintenance costs​
