ABB O3EEb HENF318176R1 Analog input control module

ABB O3EEb HENF318176R1 Analog input control module

SPECIFIC PARAMETERS​

Brand ABB​

Product Series Advant Series DCS Analog Input Module​

Product Type High-precision Multi-channel Analog Input Control Module​

Order Number HENF318176R1​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Temperature -20℃ to 60℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In-cabinet Installation)​

Installation Method DIN Rail Installation​

Number of Input Channels 16 Independent Analog Input Channels​

Input Signal Types 4-20mA 0-10V Thermocouple RTD​

Measurement Accuracy ±0.05% of Full Scale​

Isolation Feature Electrical Isolation Between Channels/Channels and Power Supply Isolation Voltage 500VAC​

Communication Protocols HART Modbus RTU Profibus DP​

Communication Rate Up to 12Mbps​

Current Consumption Typical 350mA Maximum 500mA​

Size 100mm×45mm×180mm (Standard 3U Module Size)​

Weight 0.7kg​

Power Consumption Typical 12W Maximum 18W​

Certification Qualification CE UL CSA IEC 61131-3 IEC 61010-1​

Compatible System ABB Advant DCS System Industrial Automation Platforms HART Intelligent Devices​

Sampling Rate 100Hz per Channel​

Filter Function Programmable Digital Filter Filter Time 0.1-1000ms​

PRODUCT PERFORMANCE​

16 independent analog input channels design, supporting access of multiple signal types such as 4-20mA and thermocouple, adapting to multi-parameter synchronous acquisition scenarios​

Measurement accuracy up to ±0.05% of full scale, combined with 100Hz high sampling rate, ensuring the accuracy and real-time performance of wide-range signal acquisition​

Supports HART protocol two-way communication, enabling intelligent sensor parameter configuration, fault diagnosis and data interaction without additional communication modules​

500VAC electrical isolation between channels, effectively blocking electromagnetic interference and signal crosstalk in industrial sites, improving signal transmission stability​

24VDC wide-range power supply design, resisting power grid fluctuations and voltage sags, ensuring continuous operation of the module in complex industrial environments​

Industrial-grade wide-temperature adaptation capability, can operate stably in the temperature range of -20℃ to 60℃, compatible with high and low temperature industrial scenarios​

Programmable digital filter function, filter time adjustable from 0.1 to 1000ms, adapting to control loops with different dynamic response requirements​

Modular 3U standard size with DIN rail installation, easy to install and maintain, can be flexibly combined and expanded with Advant series modules​

Uses high-quality operational amplifiers and A/D conversion chips, long-term operation drift ≤±0.01% of full scale/year, ensuring measurement stability​

Compatible with ABB Advant DCS system and third-party industrial platforms, supporting seamless integration and remote parameter configuration, reducing system integration costs​
