ABB NIMP01 Ethernet interface module

ABB NIMP01 Ethernet interface module

SPECIFIC PARAMETERS​

Brand ABB​

Product Series Industrial Network Expansion Module Series​

Product Type High-performance Ethernet Interface Expansion Module​

Communication Protocols Profinet RT/IRT EtherNet/IP Modbus TCP​

Interface Type 4 Gigabit Ethernet Copper Ports Support Auto-MDI/MDI-X Auto-negotiation​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Current Typical 0.4A Maximum 0.6A​

Working Temperature -25℃ to 70℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In-cabinet Installation)​

Data Transmission Rate 1Gbps Full-duplex/Half-duplex Auto-negotiation​

Size 100mm×45mm×160mm (Standard 3U Module Size)​

Weight 0.5kg​

Power Consumption Typical 10W Maximum 15W​

Certification Qualification CE UL CSA IEC 61158 IEC 61010-1​

Compatible System ABB System 800xA S800 Series Controllers Industrial Automation Networks​

Diagnostic Function Support Port Link Status Data Traffic Abnormal Interruption Fault Detection​

Redundancy Support Support MRP/MSTP Network Redundancy Protocol Switching Time ≤10ms​

PRODUCT PERFORMANCE​

4 Gigabit Ethernet copper ports design, supporting Auto-MDI/MDI-X auto-negotiation, enabling device interconnection without crossover cables, simplifying network deployment​

1Gbps high-speed data transmission rate, meeting the concurrent data interaction needs of multiple devices in full-duplex mode, ensuring industrial control real-time performance​

Compatible with mainstream industrial protocols such as Profinet RT/IRT and EtherNet/IP, enabling seamless access to industrial equipment of different brands, improving network compatibility​

Wide input voltage adapts to 19.2-28.8VDC, resisting power grid fluctuations in industrial sites, ensuring continuous and stable operation of the module​

Industrial-grade wide-temperature design, capable of reliable operation in the temperature range of -25℃ to 70℃, adapting to high and low temperature extreme industrial environments​

Supports MRP/MSTP network redundancy protocols, fast switching within ≤10ms when link fails, ensuring uninterrupted data transmission​

Built-in port-level diagnostic function, real-time monitoring link status, data traffic and abnormal interruptions, realizing accurate fault location and alarm​

Anti-electromagnetic interference design complies with EN 55032/EN 55035 industrial EMC standards, resisting on-site electromagnetic radiation and conducted interference, ensuring signal integrity​

Modular 3U standard size, easy to install, can be deployed collaboratively with controllers and I/O modules, saving cabinet installation space​

Supports hot-swapping operation, enabling module maintenance or capacity expansion without interrupting system operation, reducing equipment downtime​

Compatible with ABB System 800xA platform, supporting remote port configuration, status monitoring and firmware upgrade, reducing operation and maintenance costs​
