ABB LM80.A Logic control module
ABB LM80.A is a modular logic control module, belonging to the core components of ABB industrial automation control systems. The module analyzes and processes input signals through preset logic programs, generates corresponding output instructions, and realizes automated control of industrial equipment. Its design meets industrial-grade standards and can be directly connected to digital input/output modules, sensors, and actuators to build a complete automated control link.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB LM80.A Logic control module
Specific Parameters
- Number of input channels: 16 digital inputs.
- Number of output channels: 16 digital outputs (relay output, capacity 250V AC/5A).
- Operating voltage: 24V DC.
- Processing speed: Basic instruction execution time ≤0.1μs.
- Program capacity: 8KB.
- Operating temperature range: -25°C to +70°C.
- Storage temperature range: -40°C to +85°C.
- Relative humidity: 5%-95% (non-condensing).
- Communication interface: RS485 (supports Modbus RTU protocol).
- Dimensions: 120mm in length, 80mm in width, 60mm in height.
- Weight: Approximately 350g.
- Isolation method: Electrical isolation between input/output channels and power supply, isolation voltage 2.5kV AC.
Product Performance
- High-speed logic operation: It has fast processing capability, can complete complex logic judgment and instruction output within microsecond-level time, meeting the real-time control requirements of industrial equipment.
- Stable and reliable operation: Using industrial-grade components and enhanced heat dissipation design, it can work stably for a long time in harsh environments such as wide temperature and high humidity, with a mean time between failures (MTBF) ≥100,000 hours.
- Flexible programming and expansion: Supports ladder diagram (LD) and function block diagram (FBD) programming, and can increase I/O points through expansion modules, adapting to control scenarios of different scales.
- Strong anti-interference: Through electrical isolation and filtering processing, it effectively resists electromagnetic interference in industrial environments, ensuring the accuracy of signal transmission and logic operation.
- Convenient communication integration: Communicates with upper computers or other control devices through Modbus RTU protocol, realizing data interaction and remote monitoring, simplifying the system integration process.
