ABB LDSYN-101 3BHE005555R0101 Synchronous voltage measurement and signal conditioning module

ABB LDSYN-101 3BHE005555R0101 Synchronous voltage measurement and signal conditioning module

Specific Parameters

• Supported Signal Types: Supports analog signals such as 4-20mA, 0-10V; also accepts signal inputs from temperature sensors such as thermocouples (TC) and resistance temperature detectors (RTD).
• Signal Conditioning Accuracy: High-precision signal conditioning with a typical accuracy of ±0.1% FS (full scale).
• Electrical Isolation: Electrical isolation is achieved between input/output channels and between channels and the system, with an isolation voltage as high as 1500V DC.
• Operating Temperature Range: -25°C to +70°C, capable of adapting to the complex temperature environment of industrial sites.
• Protection Level: IP20, and it needs to be installed in a control cabinet for use.
• Communication Method: Achieves seamless integration with relevant ABB systems through the backplane bus; if configured as an analog input/output module, it supports HART protocol communication.

Product Performance

• Precise Synchronous Measurement: High-precision synchronous measurement and conditioning of voltage signals to ensure high-quality signal transmission, meeting the strict requirements of industrial automation systems for signal accuracy.
• Reliable Electrical Isolation: Strong electrical isolation performance effectively resists electromagnetic interference, reduces the risk of signal distortion and misoperation, and ensures the stable operation of the module in complex electromagnetic environments.
• Wide Temperature Adaptability: Can operate stably within a relatively wide temperature range, adapting to the temperature conditions of different industrial scenarios and reducing equipment failures caused by temperature changes.
• Convenient System Integration: Seamlessly integrates with relevant ABB systems, simplifies the system construction process, and facilitates users to incorporate it into the existing automation control system architecture.
• Real-time Status Monitoring: The module is equipped with built-in LED status indicators, which can intuitively display the power supply, communication, and channel status in real-time, facilitating maintenance personnel to promptly grasp the equipment operation status.
