ABB LDMTR-01 Multi functional input/output module

ABB LDMTR-01 Multi functional input/output module

Specific Parameters​

Electrical Parameters​

Operating Voltage: 24V DC, compatible with industrial standard power supply systems​

Output Voltage: 5V DC or 0~10V DC (switchable according to configuration)​

Communication Interfaces: Modbus RTU, Modbus TCP/IP, supporting Ethernet and RS-485 links​

Processor Speed: 200MHz, ensuring high-speed data processing​

Memory Capacity: 128KB program storage, meeting control logic programming needs​

Input Channels: 32 digital inputs, supporting sensor signal access​

Output Channels: 16 digital outputs, enabling equipment drive control​

Power Consumption: 5W, low-power for dense installation​

Diagnostic Functions: Integrated self-diagnosis for power failure, communication interruption and channel abnormality, with real-time status feedback​

Certification Standards: Compliant with CE, UL, FCC industrial safety standards​

Mechanical Parameters​

Overall Dimensions: 100mm (L) × 50mm (W) × 10-25mm (D), adjustable by configuration​

Weight: Approximately 100g, lightweight and compact design​

Mounting Method: 35mm DIN rail mounting, adapting to standard control cabinet layout​

Housing Material: Industrial-grade flame-retardant engineering plastic, impact and corrosion resistant​

Connection Method: Screw-type terminal blocks, compatible with ≤2.5mm² wires​

Protection Rating: IP20, suitable for installation inside control cabinets​

Status Indication: Dual-color LED indicators for operation and fault, providing intuitive device status feedback​

Environmental Parameters​

Operating Temperature: -40℃ to +85℃, covering extreme industrial working conditions​

Storage Temperature: -40℃ to +85℃, meeting storage and transportation requirements​

Relative Humidity: 5% to 95% (non-condensing), suitable for high-humidity scenarios​

EMC Compliance: Meets industrial-grade anti-interference standards, adapting to complex electromagnetic environments​

Vibration Resistance: Withstands 10-500Hz sine wave vibration without signal interruption​

Product Performance​

Excellent control precision: Dynamic compensation algorithm enables temperature measurement accuracy of ±0.1℃ and pressure measurement accuracy of ±0.01MPa​

Strong communication compatibility: Dual Modbus protocol support, seamless connection with mainstream automation systems​

Sufficient expansion capability: 32 input and 16 output channels, reducing system hardware configuration​

Excellent environmental adaptability: Wide temperature operation from -40℃ to +85℃, suitable for harsh industrial environments​

High operational stability: Industrial-grade materials and low-power design, Mean Time Between Failures (MTBF) ≥200,000 hours​

High debugging convenience: Supports remote configuration and firmware upgrade, enabling quick fault diagnosis​

Outstanding integration: Single module realizes signal processing, acquisition and control, simplifying system architecture​
