ABB JSD-TD25P-C20700 Thermostat
ABB JSD-TD25P-C20700 is a temperature controller, belonging to industrial-grade temperature control equipment. This device collects temperature signals through high-precision sensors and adjusts heating or cooling equipment in combination with built-in control algorithms to maintain the temperature stability of the target environment or object. Its design meets the needs of industrial on-site use and can be directly connected to temperature sensors and actuators to realize an automated temperature control process.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB JSD-TD25P-C20700 Thermostat
Specific Parameters
- Control Range: -50°C to 300°C.
- Control Accuracy: ±0.5°C.
- Input Signal Type: PT100, K-type thermocouple.
- Output Type: Relay output (capacity 250V AC/5A).
- Operating Voltage: 100-240V AC.
- Operating Temperature Range: 0°C to 50°C.
- Storage Temperature Range: -20°C to 60°C.
- Relative Humidity: 30%-85% (non-condensing).
- Display Mode: LED digital display with a resolution of 0.1°C.
- Dimensions: 96mm in length, 48mm in width, 112mm in height.
- Weight: Approximately 150g.
- Installation Method: DIN rail mounting or panel embedded mounting.
Product Performance
- Precise Temperature Control: Through the optimized PID control algorithm, it can quickly respond to temperature fluctuations and stabilize the temperature within the range of ±0.5°C of the set value, meeting the requirements of industrial production for temperature accuracy.
- Wide Range Adaptation: Supports multiple temperature sensor inputs, can adapt to different temperature measurement ranges and scenarios, and improves the versatility of the equipment.
- Stable Operation: Using industrial-grade components, it can work stably for a long time within the specified working environment range, reducing temperature out of control caused by equipment failures.
- Easy Operation: Equipped with simple buttons and a clear LED display, it is convenient for users to quickly set temperature parameters, check real-time temperature and operating status.
- Protection Function: It has over-temperature alarm and sensor fault detection functions. When triggered, it can automatically cut off the output and issue an alarm to ensure equipment and production safety.
